Summary of Contents for Porter-Cable PXCM024-0268
Page 1
1/2 inch (12,7 mm) Impact Wrench Clé à Chocs de 12,7 mm Llave de impacto de 12,7 mm www.portercable.com Thank you for choosing PORTER-CABLE! To register your new product, go to: www.portercable.com/ServiceAndSupport/ProductRegistration.aspx Merci d’avoir choisi PORTER-CABLE! Consulter le site Web www.portercable. com/ServiceAndSupport/ProductRegistration.aspx pour enregistrer votre nouveau produit.
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recog- nize this information, we use the following symbols. Please read the manual and pay attention to these sections.
Page 3
PERSONAL SAFETY (continued) RISK OF HEARING LOSS. Always wear ANSI S3.19 approved ear protection when using the tool. Prolonged exposure to high intensity noise is able to cause hearing loss. RISK OF EYE INJURY. Always wear ANSI Z87.1 approved safety goggles when using an air tool.
TYPICAL INSTALLATION Key Description Key Description Key Description Key Description Air hose In-line Oiler Quick Coupler Female Plug In-line Filter Air Hose Male Plug Spray Gun Tee Fitting Whip Hose w/Swivel Air Tool OPERATING INSTRUCTIONS To begin using the tool: 1.
USER-MAINTENANCE INSTRUCTIONS Air Motor Lubrication To maintain the maximum performance of the air tool, it must be lubricated each time it is used. Dust, dirt, rust and oil residue will build up inside the tool Air tool oil and reduce the performance. An in-line oiler is recommended for proper automatic tool lubrication (see Figure A).
Company. The following are PORTER-CABLE trademarks for one or more power tools and accessories: a gray and black color scheme; a “four point star” design; and three contrasting/outlined longitudinal stripes. The following are also trademarks for one or more PORTER-CABLE and Delta products: 2 BY 4®, 890™, Air America®, AIRBOSS™, Auto-Set®, B.O.S.S.®,...
LIGNES DIRECTRICES DE SÉCURITÉ—DÉFINITIONS Le présent guide contient des renseignements importants que vous devriez connaître et comprendre. Ces ren- seignements traitent de VOTRE SÉCURITÉ et de la PRÉVENTION DE PROBLÈMES DE MATÉRIEL. Pour vous aider à reconnaître les renseignements, nous avons utilisé les symboles suivants. Veuillez lire ce guide et porter une attention particulière à...
Page 8
SÉCURITÉ PERSONNELLE (suite) RISQUE DE PERTE AUDITIVE. Portez toujours des protecteurs auriculaires approuvés ANSI S3.19 lorsque vous utilisez l’outil. Une exposition prolongée à un bruit de forte intensité peut causer une perte auditive. RISQUE DE BLESSURE AUX YEUX. Portez toujours des lunettes de sécurité approuvées ANSI Z87.1 lorsque vous utilisez un outil pneumatique.
RISQUE D’EXPLOSION ET/OU DE BLESSURE. N’utilisez jamais d’oxygène, de dioxyde de car- bone, de gaz combustible ni d’autre gaz en bouteille comme source d’alimentation en air pour l’outil. De tels gaz peuvent exploser et causer des blessures corporelles graves. INSTALLATION TYPE Key Description Key Description Key Description...
MODE D’EMPLOI (suite) 9. Appuyez sur la détente pour faire fonctionner l’outil, puis relâchez-la pour l’arrêter. Débranchez l’outil de la source d’alimentation en air avant de le lubrifier ou d’en changer les douilles. ENTRETIEN PAR L’UTILISATEUR Lubrification du moteur pneumatique Pour conserver le rendement optimal du moteur pneumatique, il faut le lubrifier à...
(888)-895-4549 pour en obtenir le remplacement gratuit. GARANTIE LIMITÉE GARANTIE LIMITÉE D’UN AN : Porter-Cable Industrial Tools (la Société) garantit contre tout vice de fabrication et de main-d’œuvre, au premier acheteur au détail seulement, et ce pour une période de douze (12) mois à compter de la date d’achat, qu’elle remplacera ou réparera, sans frais, toute pièce fabriquée par la Société...
PAUTAS DE SEGURIDAD - DEFINICIONES Es importante que usted conozca y entienda la información contenida en este manual. Esta información está relacionada con la protección de SU SEGURIDAD y la PREVENCIÓN DE PROBLEMAS DE EQUIPOS. Como ayuda para reconocer esta información, utilizamos los siguientes símbolos. Por favor, lea el manual y preste atención a estas secciones.
Page 13
SEGURIDAD PERSONAL (continuación) RIESGO DE PÉRDIDA DE CAPACIDAD AUDITIVA. Utilice siempre protección auditiva con aprobación ANSI S3.19 cuando utilice la herramienta. La exposición prolongada a ruidos de alta intensidad puede causar pérdida auditiva. RIESGO DE LESIÓN OCULAR. Utilice siempre gafas de seguridad con aprobación ANSI Z87.1 cuando utilice una herramienta neumática.
RIESGO DE EXPLOSIÓN Y LESIÓN. No utilice nunca oxígeno, dióxido de carbono, gases combustibles ni ningún gas envasado como suministro de aire de la herramienta. Estos gases pueden causar explosiones y lesiones graves. INSTALACIÓN TÍPICA Key Description Key Description Key Description Key Description Manguera de aire D Engrasador en línea...
INSTRUCCIONES DE MANTENIMIENTO DEL USUARIO Lubricación del motor de aire Para conservar el funcionamiento óptimo de la herramienta neumática, debe ser lubricada cada vez que se utiliza. Las partículas, el polvo, el óxido y los residuos de aceite se acumulan dentro de la herramienta y reducen su desempeño. Se recomienda utilizar un engrasador en línea para una lubricación automática adecuada de la herramien- ta (ver Figura 1).
1-(888)-895-4549 para que se le reemplacen gratuitamente. GARANTÍA LIMITADA GARANTÍA LIMITADA DE UN A—O: Porter-Cable Industrial Tools (la Empresa) garantiza que durante un período de doce (12) meses a partir de la fecha de adquisición, cambiará o reparará de forma gratuita y únicamente al comprador minorista original, toda parte o partes, fabricadas por la empresa, que la empresa o sus representantes designados determinen que presentan defectos de material, mano de obra o ambos.
