90565239 REV 1 PCL120ID 12 V Lithium Impact Driver.qxd:??????-00 Cir Saw book
12V Max* 1/4 inch (6.35mm)
Cordless Impact Driver
Visseuse à percussion sans fil,
de 12V max*, 6,35 mm (1/4 po)
Destornillador de impacto inalámbrico
de 12V máx* 6,35 mm (1/4 pulgada)
*Maximum initial battery pack voltage (measured
without a workload) is 12 volts. Measured under a
workload, nominal voltage is 10.8.
Instruction manual
Manuel d'instructions
Manual de'instrucciones
www.portercable.com
INSTRUCTIVO DE OPERACIÓN,
CENTROS DE SERVICIO Y PÓLIZA DE
GARANTÍA.
ADVERTENCIA: LÉASE ESTE
INSTRUCTIVO ANTES DE USAR EL
PRODUCTO.
CATALOG NUMBER
PCL120ID
6/25/10
2:41 PM
Page 1
