9.4 Outdoor Unit Electrical Components
ANL-100, AVL-100, AVL-120, AVL-140 (Outdoor Unit Electrical Components)
No. in
Part Description
Fig. 9-4
1 Axial Fan With Protection Screen
2 Electrical Board Base Plate
3 Electrical Board Inner Cover
4 Compressor Contactor
5 Fan Contactor
6 Normally Open Relay
7 RST Controller
8 Fastener
9 Connection Fastener
10 Grounding Fastener
11 Neutral Fastener
12 RST Connection Fastener
13 Fastener Spacer
Quantity
ANL-100
Per Unit
AVL-100
2 4060R13
1 PCUC100017
1 PCUC100022
1 1001NC25
2 1001NC09
2 1001G7L0
1 1001RSTC
6 10060013
18 10060007
6 10060009
6 10060008
3 10060010
9 10060006
- 50 -
Parts No.
AVL-120 AVL-140
4060R13 4060R13
PCUC100017 PCUC100017
PCUC100022 PCUC100022
1001NC25 1001NC25
1001NC09 1001NC09
1001G7L0 1001G7L0
1001RSTC 1001RSTC
10060013 10060013
10060007 10060007
10060009 10060009
10060008 10060008
10060010 10060010
10060006 10060006
