7.9 Installing the Wall Mounted Unit and the Remote Control

• Remove the two units illustrated in Figure 6-10 from their packaging.
• Attach each unit to the wall with two screws. Use the template attached to the packaging to
assist in positioning the screws for the wall mounted unit.
• The two units must be positioned in the same room in such a way that there is an unimpeded
line of sight between them.

7.10 Wiring the Indoor and Outdoor Units.

3 PHASE ELECTRICAL DIAGRAM

INDOOR UNIT
1
3
4
5
7
10
2
6
8
9
OUTDOOR SENSOR CABLE (Th3)
Fig. 7-10
OUTDOOR UNIT
BLACK
BROWN
YELLOW
WHITE
BLUE
GREEN / YELLOW
Fig. 7-11
- 32 -
1
OUTDOOR 3 PHASE
2
POWER CABLE
3
7
6
R
S
T
N
R S T N
