Zoom R16 Operation Manual page 45

R16 effect types and parameters 9
8x Comp EQ algorithm
Modules 1~8
Unit Type
HPF 1-8 HPF
COMP/LIMITER Rack Comp
1-8 Limiter
3BAND EQ 1-8 3Band EQ
Parameter description
Parameter
Setting range
name
Frequency 80~240Hz
MASTERING algorithm
COMP/Lo-Fi module
Type
Xover Lo Xover Hi Sense Hi
3Band Comp Compressor that divides the signal into three frequency bands and allows individual adjustment of compressor sensitivity and
mixing ratio for each band.
Lo-Fi For an explanation of types and parameters, see STEREO algorithms.
Parameter descriptions
Parameter
Setting range
name
Xover Lo 50Hz~16kHz
Xover Hi 50Hz~16kHz
Sense Hi 0~24
Sense Mid 0~24
Sense Low 0~24
Mix High Off, −24~6
Mix Mid Off, −24~6
Mix Low Off, −24~6
NORMALIZER module
Type
Gain
Normalizer
Adjusts COMP/Lo-Fi module input level.
Parameter description
Parameter
Setting range
name
Gain −12~12
3BAND EQ module
Type
3Band EQ For an explanation of types and parameters, see CLEAN, DISTORTION, ACO/BASS SIM algorithms.
DIMENSION/RESO module
Type
Dimension
For an explanation of types and parameters, see STEREO algorithms.
Resonance
ZNR module
Type
ZNR For an explanation of types and parameters, see CLEAN, DISTORTION, ACO/BASS SIM algorithms.
87
Parameter
Frequency
High-pass filter blocks the low range and passes high frequencies.
For an explanation of types and parameters, see CLEAN,
DISTORTION, ACO/BASS SIM algorithms.
Description
Adjusts cutoff frequency.
Parameter
Sense Mid Sense Low Mix High Mix Mid Mix Low
Description
Adjusts low-to-mid crossover frequency.
Adjusts mid-to-high crossover frequency.
Adjusts high range compressor sensitivity.
Adjusts mid range compressor sensitivity.
Adjusts low range compressor sensitivity.
Adjusts high range mixing ratio.
Adjusts mid range mixing ratio.
Adjusts low range mixing ratio.
Parameter
Description
Adjusts level.
Parameters/Description
Parameters/Descriptions
Parameters/Description
R16 effect types and parameters 10
Send/return effect
CHORUS/DELAY module
Type
LFO Type Depth
Chorus
Mixes a variable pitch-shifted component with the original sound, resulting in full-bodied resonating tone.
Time Feedback Hi Damp
Delay
Delay effect with a maximum setting of 2000 ms.
Parameter descriptions
Parameter
Setting range
name
LFO Type Mono, Stereo
Depth 0~100
Rate 1~50
Pre Delay 1~30
0~100
EFX Level
Rev Send 0~30
Time 1~2000ms (P.86 Table 1)
Feedback 0~100
Hi Damp 0~10
Pan Left10~Left1, Center, Right1~Right10
REVERB module
Hall Simulates the acoustics of a concert hall.
Room Simulates the acoustics of a room.
Pre Delay Decay
Hall and Room have the same parameters.
Spring Simulates a spring reverb.
Plate Simulates a plate reverb.
Pre Delay Decay
Spring and Plate have the same parameters.
Parameter description
Parameter
Setting range
name
1~100
Pre Delay
Decay 1~30
EQ High −12~6
EQ Low −12~6
E.R.Mix 0~30
EFX Level 0~100
Parameters/Descriptions
Rate Pre Delay EFX Level
Pan EFX Level Rev Send
Description
Sets LFO phase to mono or stereo.
Adjusts effect depth.
Adjusts modulation rate.
Adjusts pre-delay time.
Adjusts effect sound level.
Adjusts delay sound reverb send level.
Adjusts delay time.
Adjusts feedback amount.
Adjusts intensity of delay sound high range damping.
Adjusts delay sound panning.
Parameters/Descriptions
EQ High EQ Low E.R.Mix EFX Level
EQ High EQ Low EFX Level
Description
Adjusts pre-delay time.
Adjusts reverb time.
Adjusts high range effect sound.
Adjusts low range effect sound.
Adjusts mix ratio of initial reflections.
Adjusts effect sound level.
88
