Zoom R16 Operation Manual page 22

Mix down/Bounce
Using a mastering effect
Use a mastering algorithm as an insert effect on the master track that affects just the mix down.
Insert an INSERT EFFECT before
the [MASTER] fader.
1
Press [INSERT EFFECT].
Effect ON/OFF switch
If "INSERT EFFECT Off" is displayed,
press [ENTER].
Change algorithms
C L E A N < I N 1 >
N o . 0 0 : S t a n d a r d
2
MASTERING .
Select
M A S T E R I N G < I N 1 / 2 >
N o . 0 0 : P l u s A l f a
Change menus
3
Press[ ].
N o . 0 0 : P l u s A l f a Change menus
> E D I T
4
Select >INPUT SOURCE
N o . 0 0 : P l u s A l f a
> I N P U T S O U R C E
Press [ENTER].
I n p u t S o u r c e
I N P U T 1
5
Change input
Select MASTER.
I n p u t S o u r c e
M A S T E R
Press [ENTER].
N o . 0 0 : P l u s A l f a
Change menus
> E D I T
6
Press[ ].
M A S T E R I N G < M A S T E R >
N o . 0 0 : P l u s A l f a
41
7
Select the patch.
M A S T E R I N G < M A S T E R >
N o . 0 3 : D i s c o M s t
Audition the patches while
listening to the tracks playback,
and then select one.
8
Press [EXIT].
P R J 0 0 1 < M A S T E R >
0 0 0 0 0 : 0 0 : 0 0 0
NOTE
• If the INSERT EFFECT is applied to the [MASTER]
fader, you cannot also use the INSERT EFFECT
on track inputs.
• At step 7, if you notice any distortion of the signals
because of the MASTERING EFFECT, check
the sound of playback on the track and adjust
it by lowering all the faders. (If a track sound is
distorted, adjust that track.)
• You can select STEREO, DUAL, MIC or MASTER
algorithms. If you set another algorithm, the insert
position changes to the inputs.
.
HINT
• When you choose a MASTERING algorithm, you
can use the MASTERING EFFECT processing on
the stereo mix.
Recording signal flow to the master track
Mix down/Bounce
Recording to the master track
Record a "final" stereo mix as a mix down on the [MASTER] track. Signals are recorded to the [MASTER]
track after passing through the [MASTER] fader.
Recording to the [MASTER] track.
Preparation: Adjust the signal levels.
Change patch
1
Play the tracks, and adjust the
mix balance of the tracks.
2
Adjust the level of the signal that
passes through the master fader.
Red
Orange
Green
Green
3
Press [STOP].
Recording to the master track
4
Red light on: recording enabled
5
6
7
Press [STOP] to stop
recording.
NOTE
The settings of the pan/balance, insert and send/
return effects of each track affect the signals sent to
the master track and are reflected in its sound.
Play the master track
1
Press [REW] + [STOP]
at the same time and
Green light on: playback enabled
then [PLAY] to start
Doing this mutes the other tracks and
playback from the top.
disables all effects.
2
Press [PLAY] to start
playback.
3
Press [STOP] to stop playback.
Carefully control
the level so as
not to light the
Disable master track playback.
red indicator
(clip=0dB).
4
Light off: muted
HINT
Press [MASTER/MIX
DOWN/PLAY] 1-2
times until the red light
• Each project can have one master track.
turns on.
• The master track will have a file assigned.
• During recording you can confirm the playback
levels of each track and the recording levels of
the master track.
Press [REW] & [Stop] at • The signals sent from the OUTPUT jacks are
the same time to return the same signals that have passed through the
the counter to the head. [MASTER] fader.
• You can use the [UNDO/REDO] key.
• You can use the metronome during playback.
Press [REC] and [PLAY]
in turn to start recording.
Consecutive playback of
multiple master tracks.
Press [MASTER/MIX
DOWN/PLAY] 1-2 times
until the green light
turns on.
Press [REW] & [Stop] at
the same time to return
the counter to the head.
Press [MASTER/MIX
DOWN/PLAY] 1-2
times until the light
turns off.
Muting of the other tracks
is canceled and their status
lights become as they were
before enabling master track
playback.
No.65
