Effect
Insert effect
: Patch save
Send return effect
Once you have edited a patch, use "SAVE" to save it. You can save a patch at any place within
the same algorithm.
1
Press [INSERT
or
EFFECT] or
[SEND RETURN
EFFECT].
Effect ON/OFF switch
When "INSERT EFFECT Off" is displayed,
press [ENTER].
2
Select the algorithm/patch.
Change
algorithm
C L E A N < I N 1 >
N o . 1 5 : S t a n d a r d E
Patch has been edited
Change
3
Press [ ].
4
Select >SAVE .
Change
N o . 0 0 : S t a n d a r d
> S A V E
Press [ENTER].
5
Select the place to save.
Change place to
S a v e t o
N O . 2 9 : E m p t y
Save location number: patch name
Press [ENTER].
6
Execute [SAVE] action.
N O . 2 9 : E m p t y
S a v e ?
Press [ENTER].
53
patch
menu
save
NOTE
• These procedures are the same for both insert
and send return effects.
• If you switch to another patch without saving
an edited patch, you will lose all the edits.
Remember to always save your edited patches.
• The import source and the import destination are
different projects when using PATCH IMPORT.
HINT
• You can save your edited patch at any place within
the same algorithm.
• You can make a patch copy by saving an existing
patch to a different area.
Effect
Insert effect
: Patch import
Send return effect
Import one or all patches that have been created in another project to use in the current project.
See steps 1~3 on the previous
page.
4
Select >IMPORT .
Change
menu
N o . 0 0 : S t a n d a r d
> I M P O R T
Press [ENTER].
5
Change menu. Select import method.
P A T C H I M P O R T
> A L L
Change
menu/item
Change menu>ALL: import all patches from the
target project
Change menu>PATCH: select one patch and
import it from the target project
Import all patches.
IMPORT>ALL
1
Select >ALL .
P A T C H I M P O R T
> A L L
Change item
Press [ENTER].
2
Select the project to import from.
A L L P A T C H I M P O R T
N o . 0 0 1 : P R J 0 0 1
Change
Source project number and name
project
Press [ENTER].
3
Confirm the project to import from
and press [IMPORT].
N o . 0 0 1 : P R J 0 0 1
A l l P a t c h I m p o r t ?
Press [ENTER].
Import one patch.
IMPORT>PATCH
1
Select >PATCH .
P A T C H I M P O R T
> P A T C H
Change item
Press [ENTER].
2
Select the project to import from.
P A T C H I M P O R T
N o . 0 0 1 : P R J 0 0 1
Source project number and name
Change
project
Press [ENTER].
3
Select the patch to import.
I m p o r t
N o . 0 0 : S t a n d a r d
Change
Source patch number
patch
Press [ENTER].
4
Select the patch to import.
I m p o r t t o
N o . 0 0 : S t a n d a r d
Change
Destination patch number
place to save
(save location)
Press [ENTER].
5
Import the patch.
N O . 0 1 : E n s e m b l e
I m p o r t ?
Press [ENTER].
