OSD Operation

1st Tier Option
CONTRAST
BRIGHTNESS
FINETUNE
COLOR
OUTPUT
AUDIO
OSD
INFORMATION
EXIT
Instruction Manual
2nd Tier
Option
HUE
SATURATION
SHARPNESS
EXIT
RED
GREEN
BLUE
EXIT
HPOSITION
VPOSITION
TIMER
TRANSP
EXIT
Adjustment/Function
0 ~ 100% of Contrast Level
0 ~ 100% of Brightness Level
0 ~ 100% of Hue Level
0 ~ 100% of Saturation Level
0 ~ 100% of Sharpness Level
Back to 1st Tier
0 ~ 100% of Red Color Level
0 ~ 100% of Green Color Level
0 ~ 100% of Blue Color Level
Back to 1 Tier
NATIVE / VGA / SVGA / XGA / SXGA /
UXGA / 480i / 480p / 720p@60Hz /
1080i@60Hz / 1080p@60Hz / 576i / 576p /
720p@50Hz / 1080i@50Hz /1080p@50Hz /
WXGA / WSXGA / WUXGA
HDMI / EAR PHONE / OPTICAL
0 ~ 100% of OSD Horizontal Position
0 ~ 100% of OSD Vertical Position
0 ~ 100% of OSD Existing Time (sec.)
0 ~ 100% of OSD Transparent Level
Back to 1st Tier
SOURCE (Input Interface)
INPUT (Input Resolution)
OUTPUT (Output Resolution)
VERSION (Firmware Version)
Close OSD Menu
