Kantech Door Controller Innovative and Powerful KT-300 Specifications

Door controller

Hide thumbs Also See for Door Controller Innovative and Powerful KT-300:

Download this manual See also: Installation Manual

KT-300

• Controls two doors and easily links to a network

• Update the firmware directly from the system workstation

• Fast, up to 115,200 baud

• Ready to go, no dip switches or jumpers to set

• 5V and 12V reader power

• Interfaces with an external alarm system

• Automated trouble reporting

Door Controller

INNOVATIVE AND POWERFUL

Page 1 KT-300 • Controls two doors and easily links to a network • Update the firmware directly from the system workstation • Fast, up to 115,200 baud • Ready to go, no dip switches or jumpers to set • 5V and 12V reader power •...
Page 2: Ordering Information
KT-300 Door Controller INNOVATIVE AND POWERFUL The KT-300 is a two door controller designed to meet the highest standard of access control and monitoring point applications. KT-300 Technical Specifications Input power 16 VAC, 40VA, class 2 transformer Battery backup 1 battery 12V, 7Ah, supervised, provides operation for up to 12 hours Dimensions 29.9 x 28.8 x 7.7 cm (11.75 x 11.38 x 3 in) EMT 1.9 cm (0.8 in)
