Dimensions
XC-ES50/50CE/ES30/30CE/
ES51/51CE/EI50/50CE/EI30/
30CE
14.5
(19/32)
2-M2 deep 3
15
(19/32)
4-M2 deep 3
3-M3 deep 3
16.5
(21/32)
Note
The dimensions shown above are for the
models with the following serial numbers.
XC-ES50/EI50/ES30/EI30: 250001 or later.
XC-ES51: 150001 or later.
XC-ES50CE/EI50CE/ES30CE/EI30CE:
550001 or later.
XC-ES51CE: 450001 or later.
Top
Bottom
23.7
(15/16)
22
(7/8)
42
1
(
7/16)
Side
CCD
XC-ES50
(4.9)
(7/32)
12
30
1
(
3/16)
(1/2)
CCD side
29
1
(
3/16)
Appendix
5.1
8
(7/32)
(5/16)
Unit: mm (inches)
25
