Sony XC-ES50/50CE Technical Manual Page 23

Ccd black-and-white video camera module.
Hide thumbs

Advertisement

S/N ratio
60 dB
Minimum illuminance
(F1.4, γ=ON, MAX GAIN, without IR cut filter)
XC-ES50/50CE, XC-ES30/30CE:
0.3 lx
XC-ES51/51CE: 0.2 lx
XC-EI50/50CE: 0.1 lx
XC-EI30/30CE: 0.2 lx
Gain
AGC/Manual
(Can be selected using the switch on
the rear panel)
Gamma compensation
ON/OFF
(Can be selected using the switch on
the rear panel)
Electronic shutter
XC-ES50/EI50/ES51:
1/100 to 1/10,000 second
XC-ES30/EI30:
1/100 to 1/10,000 second
XC-ES50CE/EI50CE/ES51CE:
1/120 to 1/10,000 second
XC-ES30CE/EI30CE:
1/120 to 1/10,000 second
External trigger shutter
XC-ES50/EI50/ES51:
1/4 to 1/10,000 second
XC-ES30/EI30:
1/4 to 1/10,000 second
XC-ES50CE/EI50CE/ES51CE:
1/4 to 1/8,000 second
XC-ES30CE/EI30CE:
1/4 to 1/8,000 second
* Can be changed using the trigger
pulse width or set using the DIP
switches on the rear panel.
Power requirement
DC +12 V (+9.0 V to 16 V)
Power consumption
XC-ES30/30CE, XC-EI30/30CE:
1.4 W
XC-ES50/50CE, XC-EI50/50CE,
XC-ES51/51CE: 1.6 W
Operating temperature
–5 °C to +45 °C (23 °F to 113 °F)
Storage temperature
–20 °C to +60 °C (–4 °F to 140 °F)
Performance assurance temperature
0 °C to +30 °C (32 °F to 86 °F)
Operating humidity
20 to 80% (Non-condensing)
Storage humidity
20 to 95% (Non-condensing)
Vibration resistance
10 G
(For 20 minutes in the X,Y and Z
directions at 20 to 200 Hz)
Shock resistance 70 G
Outside dimensions
29 (W) × 29 (H) × 30 (D) mm
(W) × 1
3
(1
/
16
inches)
Weight
50 g (2 oz)
Standards
UL1492, FCC Class B Digital Device,
CE (EN50081-2+EN50082-2)
Accessories
Lens mount cap (1)
Operating Instructions (1)
MTBF
126,469 H (approx. 14.4 years)
* Note on using the XC-EI50/EI50CE, EI30/EI30CE:
The output levels for the odd field and the even field may
differ in frame accumulation mode.
External synchronization for each mode
Internal sync
Mode
Normal
Normal shutter
Mode 1
External
trigger
Trigger signal generates
shutter
an internal VD signal
Mode 2
(single).
Restart/reset
Ο
: Available
×: Not available
Appendix
(H) × 1
3
3
/
/
(D)
16
16
External sync
HD/VD
O
O
O
O
O
O
O
23
