Sony XC-ES50 Brochure

Xc-e series b/w video cameras.
Hide thumbs


Advertisement

Component/OEM
OUTLINE
The XC-E Series are compact, light-weight one-piece black and white
cameras incorporating the latest 1 /2 and 1 /3 type Interline (IT) CCD
which produces new levels of picture detail.
29 x 29 x 32 mm (1 3 /16 x 1 3 /16 x 1 5 /16 inches)*, these cameras can
easily be installed in places where installation was previously difficult
for larger cameras.
The XC-E Series is a family of cameras with different spectral
sensitivities and shapes to suit a variety of application environments.
The XC-ES Series (XC-ES50/ES50CE, XC-ES50L/EX50LCE, XC-
ES51/ES51CE and XC-ES30/ES30CE) are standard models to be used
under visible light conditions that range in sensitivity from 0.2 lx to 3.0
lx. The XC-ES50L/50LCE features a unique L shape compact body that
makes it easy to install in short spaces — only 53mm from the
c-mount to the top of the camera. The XC-EI Series (XC-EI50/EI50CE
and XC-EI30/EI30CE) offer excellent near-infrared sensitivity. Under low
light conditions or when used with IR LED illumination systems, these
cameras provide clear images. The XC-EU Series (XC-EU50/EU50CE)
offer near-ultraviolet sensitivity in the i-line, or 365 nm, range. The short
wavelength allows the XC-EU Series to capture very fine details.
All models have identical dimensions and controls, making them easy
to interchange. A variety of settings are available for differing subject
and lighting conditions. All camera control switches are accessible
from the outside of the camera.
characteristics make these cameras ideal for demanding machine
vision applications.
*The XC-ES50L/ES50LCE, which are L-type versions of the XC-ES50/ES50CE, measure
3
29 (W) x 42.5 (H) x 43.8 (D) mm (1
/
x 1
16
XC-E Series
With dimensions of
Excellent vibration and shock
11
3
/
x 1
/
inches) without C-mount or connectors.
16
4
B/W VIDEO CAMERAS
XC-ES50/ES50CE
XC-ES50L/ES50LCE
XC-ES51/ES51CE
XC-ES30/ES30CE
XC-EI50/EI50CE
XC-EI30/EI30CE
XC-EU50/EU50CE
FEATURES
XC-ES50/ES50CE/ES50L/ES50LCE/ES51/ES51CE/EI50/EI50CE/
EU50/EU50CE: 1/2 type IT CCD
XC-ES30/ES30CE/EI30/EI30CE: 1/3 type IT CCD
Compact and light weight:
29 (W) x 29 (H) x 32 (D) mm, 50 g (1
except for XC-ES50L/ES50LCE which measures:
29 (W) x 42.5 (H) x 43.8 (D) mm, 110 g (1
Near-infrared sensitivity: XC-EI50/EI50CE, XC-EI30/EI30CE
Near-ultraviolet sensitivity: XC-EU50/EU50CE
Minimum illumination at F1.4:
0.3 lx: (XC-ES50/ES50CE/ES30/ES30CE)
3.0 lx: (XC-ES50L/ES50LCE)
0.1 lx: (XC-EI50/EI50CE)
0.2 lx: (XC-ES51/ES51CE/EI30/EI30CE)
High S/N Ratio: 60 dB
Electronic shutter function:
1
/
to
1
/
s: EIA/
1
/
to
1
/
100
10,000
120
10,000
Flexible trigger shutter function
Scanning system: 2:1 interlaced
Frame/field exposure
Restart/reset function
Synchronization: internal/external (HD/VD)
High shock and vibration tolerance
3
/
x 1
3
/
x 1
5
/
inches, 2 oz):
16
16
16
3
11
3
/
x 1
/
x 1
/
inches, 4 oz)
16
16
4
s: CCIR

Advertisement

Table of Contents

   Related Manuals for Sony XC-ES50

   Summary of Contents for Sony XC-ES50

  • Page 1 Excellent vibration and shock characteristics make these cameras ideal for demanding machine vision applications. *The XC-ES50L/ES50LCE, which are L-type versions of the XC-ES50/ES50CE, measure 29 (W) x 42.5 (H) x 43.8 (D) mm (1 inches) without C-mount or connectors. B/W VIDEO CAMERAS...
  • Page 2: Connection Diagram

    CONNECTION DIAGRAM C-mount lens VCL-08YM VCL-12YM VCL-16Y-M VCL-25Y-M VCL-50Y-M LO-77ERK Extension rings kit DIMENSIONS & REAR PANEL XC-ES50/ES50CE/ES51/ES51CE/ES30/ES30CE XC-EI50/EI50CE/EI30/EI30CE/EU50/EU50CE Unit: mm 12-pin multi-connector PIN No. External sync (HD/VD) +12V DC Video output External HD input External VD input*1 – WEN output*2 TRIG input *1 An input VD signal is required when using restart, reset mode.
  • Page 3: Specifications

    SPECIFICATIONS XC-ES50 Image device Effective picture elements Signal system Horizontal frequency Vertical frequency Cell size (µm) Lens mount Flange back Sync system External sync system External sync frequency Jitter Scanning system Video output Horizontal resolution Sensitivity (Gamma ON, MIN GAIN, 400 lx F5.6...
  • Page 4 Standard model XC-ES50/ES50CE XC-ES50L/ES50LCE XC-ES51/ES51CE XC-ES30/ES30CE Applicable wavelength range 400-770 nm UV model XC-EU50/EU50CE Applicable wavelength range 300-420 nm ACCESSORIES Compact camera adaptor 12-pin camera cable (CE standard) DC-700/700CE CCXC-12P02N (2 m) Compact, lightweight (700 g, 1 lb 8 oz)
