SMARTLF DOCUMENT SIZES

SmartLF has AutoSize, ISO, ANSI and ARCH paper sizes which can be selected
from the Paper size scroll box.
NOTE: The effectiveness of Auto Size can be affected by the type of media loaded
in SmartLF. For example transparent or non-square media may fail to auto size
correctly.
Although SmartLF does not allow custom paper size scanning the product does
permit any document appearing in the preview window to be cropped before being
processed further. This is especially useful for extracting parts of larger drawings
for emailing to colleagues, other offices or saving to disk.

THE SMARTLF PREVIEW WINDOW

CROPPING IN SMARTLF

Use SmartLF CROP IMAGE to select an area of the image for scanning to
file, to the Windows printer or email.
Pressing the CROP IMAGE icon on the Preview toolbar places a green crop
square onto the currently displayed image. Use the grips at the corners to
resize the crop boundaries. Clicking and holding the mouse button down on
the centre of the square will move it across the image.

COPYING FROM SMARTLF

SmartLF uses any standard Windows printer driver for copying. The number
of copies can be controlled from the COPY button by clicking on the + and –
icons.
The print quality of the copy is controlled from the Windows driver Properties
dialogue in the normal way.
SmartLF will copy all images at 1:1 i.e. no scaling will take place unless
configured at the windows driver itself.
PAS144
Colortrac SmartLF Installation and Operating Manual
DISCARD
ZOOM IN
ZOOM OUT
FILE IMAGE
CROP IMAGE
