12
NOTE: For fragile originals SmartLF can be slowed down using the Quality slider accessed from the i-box in the
top left corner of the SmartLF interface.
As soon as the required function is selected SmartLF begins to scan the document
loaded in the scanner or waits for the document to be loaded. SmartLF will display
the animated icon showing a document being loaded into the scanner.
PRESSING THE RUNNING FUNCTION HOURGLASS ICON STOPS SMARTLF
SmartLF can also be controlled from the scanner's control panel by pressing the
corresponding BLUE panel buttons. These will only operate the SmartLF software
if they have been correctly configured through the Windows XP Cameras and
Cameras icon that is located in the Windows XP Control Panel. Refer to Sect. 10.

SMARTLF HAS THREE COLOUR MODES

COLOR
The color mode allows control
of the number of colours and
the brightness of the file, copy
or emailed document image
12.

OPENING AND CLOSING THE COVER

The SmartLF Cover provides access to the document pressure adjustment mechanism. Open the cover by lifting it
firmly from the front and centre with two hands so that it swings open and backward slightly beyond the vertical
position.
PAS144
Colortrac SmartLF Installation and Operating Manual
COPY
EMAIL
GRAYSCALE
The grayscale mode allows
control of the brightness of the
file, copy or emailed document
FILE
BLACK AND WHITE
The black and white mode
allows control of the type and
degree of thresholding of the
file, copy or emailed document
SmartLF Cover in the open position
showing the two pressure adjustment
sliders
P/N: P002038 Colortrac Ltd © 2004
