Page 1: Quick Installation Guide
EAX-785E AMD Turion /Athlon II Neo Processor Quick Installation Guide Ed – February 8 2011 Part No. E2017785E00R... - Page 2 CORRECT THE INTERFERENCE AT HIS OWN EXPENSE. Copyright Notice Copyright © 2011 Avalue Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
- Page 3 Room 805, Building 9,No.99 Tianzhou Rd., 2F keduka-Bldg, 2-27-3 Taito, Caohejing Development Area, Taito-Ku, Tokyo 110-0016 Japan Xuhui District, Shanghai Tel: +81-3-5807-2321 Tel: +86-21-5169-3609 Fax:+86-21-5445-3266 Fax: +81-3-5807-2322 Information: sales.china@avalue.com.cn Information: sales.japan@avalue.com.tw Service: service@avalue.com.tw Service: service@avalue.com.tw EAX-785E Quick Installation Guide 3...
-
Page 4: Table Of Contents
2.3.13.1 Signal Description – LCD Inverter Connector (JBKL1)) ......16 2.3.14 General Purpose I/O connector (JDIO1) ..........17 2.3.15 LVDS connector (JLVDS1)..............18 2.3.16 Cross fire Power connector (XFIRE_PWR1).........19 2.3.17 SPI programming connector (SPI1) ............19 2.3.18 USB connector 56 & 78 (USB56/78) .............20 4 EAX-785E Quick Installation Guide... -
Page 5: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following items have been shipped: 1 x EAX-785E ATX Main Board 2 x SATA cable kit(SATA/power) COM 9P Cable W/O Bracket PH:2.00mm 1 x DRIVER CD (CD-R) without printed LOGO... -
Page 6: Hardware Configuration
EAX-785E Quick Installation Guide 2. Hardware Configuration 6 EAX-785E Quick Installation Guide... -
Page 7: Product Overview
EAX-785E Quick Installation Guide 2.1 Product Overview EAX-785E Quick Installation Guide 7... -
Page 8: Jumper And Connector List
Label Function Note Clear CMOS 3 x 1 header, pitch 2.54 mm CLRTC1 Amplifier controller 5 x 1 header, pitch 2.54 mm CN21 JCOMPWR1/2/3/4 Power Selector 3 x 2 header, pitch 2.54 mm Ring /+5V/+12V 8 EAX-785E Quick Installation Guide... - Page 9 4 x 1 wafer, pitch 5.08 mm XFIRE_PWR1 SATA1/2/3/4/5 Serial ATA connector 1/2/3/4 SPI programming connector 3 x 2 header, pitch 2.54 mm SPI1 USB connector 56 & 78 5 x 2 header, pitch 2.54 mm USB56/78 EAX-785E Quick Installation Guide 9...
-
Page 10: Setting Jumpers & Connectors
EAX-785E Quick Installation Guide 2.3 Setting Jumpers & Connectors 2.3.1 Clear CMOS (CLRTC1) Normal * Clear * Default 2.3.2 Amplifier Controller (CN21) VR connection* Signal PORT_A_R LOUT_RR PORT_A_L LOUT_LL * Default 10 EAX-785E Quick Installation Guide... -
Page 11: Power Selector Ring/+5V/+12V (Jcompwr1)
EAX-785E Quick Installation Guide 2.3.3 Power selector Ring (JCOMPWR1) /+5V/+12V Ring * +12V * Default 2.3.4 Power selector Ring (JCOMPWR2/3/4) /+5V/+12V Ring * +12V 4 3 2 * Default EAX-785E Quick Installation Guide 11... -
Page 12: Atx Power Connector (Atxpwr1)
EAX-785E Quick Installation Guide 2.3.5 ATX power connector (ATXPWR1) Signal PIN PIN Signal +12V +5VSB ATX_PWRGD PSON# +3.3V -12V +3.3V +3.3V 2.3.6 AT Power connector (ATX12V1) Signal PIN PIN Signal +12V_VCORE +12V_VCORE 12 EAX-785E Quick Installation Guide... -
Page 13: Azalia Front Audio Connector (Aafp1)
EAX-785E Quick Installation Guide 2.3.7 Azalia Front audio connector (AAFP1) Signal PIN PIN Signal MIC2_L MIC2_R FP_PRES# LIN2_R SRTN1 SENSE_B LIN2_L SRTN2 2.3.8 Chassis Fan connector (CHA_FAN1) Signal +12V SFAN_TACH EAX-785E Quick Installation Guide 13... -
Page 14: Cpu Fan Connector (Cpu_Fan1)
EAX-785E Quick Installation Guide 2.3.9 CPU Fan connector (CPU_FAN1) Signal +12V CFAN_TACH CFAN_PWM 2.3.10 Serial port 2/ 3/ 4 connector (COM 2/3/4) Signal PIN PIN Signal DDCD2# RRXD2 TTXD2 DDTR2# DDSR2# RRTS2# CCTS2# COM2P9SEL 14 EAX-785E Quick Installation Guide... -
Page 15: System Panel Connector (F_Panel1)
EAX-785E Quick Installation Guide 2.3.11 System Panel connector (F_PANEL1) Signal PIN PIN Signal SYS_RST# PWRBTN# PLED- HPLED- PLED+ HDLED+ 2.3.12 Amplifier connector (JAMP1) Signal EAX-785E Quick Installation Guide 15... -
Page 16: Lcd Inverter Connector (Jbkl1)
For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal. 2.3.13.1 Signal Description – LCD Inverter Connector (JBKL1)) Signal Signal Description BRIGHT Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W) LBKLT_EN LCD backlight ON/OFF control signal 16 EAX-785E Quick Installation Guide... -
Page 17: General Purpose I/O Connector (Jdio1)
EAX-785E Quick Installation Guide 2.3.14 General Purpose I/O connector (JDIO1) Signal Signal GPIO0 GPIO4 GPIO1 GPIO5 GPIO2 GPIO6 GPIO3 GPIO7 +5V_USB_R EAX-785E Quick Installation Guide 17... -
Page 18: Lvds Connector (Jlvds1)
EAX-785E Quick Installation Guide 2.3.15 LVDS connector (JLVDS1) Signal PIN PIN Signal +3.3V +3.3V I2C_CLK I2C_DATA B_CK+ A_CK+ B_CK- A_CK- +12V +12V 18 EAX-785E Quick Installation Guide... -
Page 19: Cross Fire Power Connector (Xfire_Pwr1)
EAX-785E Quick Installation Guide 2.3.16 Cross fire Power connector (XFIRE_PWR1) Signal +12V 2.3.17 SPI programming connector (SPI1) Signal Signal +3.3V DATAIN DATAOUT HOLD# EAX-785E Quick Installation Guide 19... -
Page 20: Usb Connector 56 & 78 (Usb56/78)
EAX-785E Quick Installation Guide 2.3.18 USB connector 56 & 78 (USB56/78) Signal Signal +USBV4567 +USBV4567 20 EAX-785E Quick Installation Guide...
