Page 1: Digital Video Recorder
X-Series Digital Video Recorder Hardware Manual OE3-X12004M model no. Pleas e carefully r ead these instructions before u sing th is prod uct. Savethis manual f o r future use. 28170AC... - Page 2 (including without limitation, damages for loss of business profits, business interruption or loss of business information), even if OPENEYE has been advised of the possibility of such damages and whether in an action or contract or tort, including negligence.
-
Page 3: Important Safeguards
Object and Liquid Entry Points – Never insert foreign objects into the DVR unit, other than the media types approved by OpenEye, as they may touch dangerous voltage points or short-out parts that could result in a fire or electrical shock. Never spill liquid of any kind on the product. -
Page 4: Notes On Handling
IMPORTANT SAFEGUARDS, continued Damage Requiring Service – Unplug the unit from the outlet and refer servicing to qualified service personnel under the following conditions: When the power-supply cord or plug is damaged. If liquid has been spilled, or objects have fallen into the unit. If the unit has been exposed to rain or water. -
Page 5: Notes On Maintenance
NOTES ON CLEANING Use a soft dry cloth for cleaning. For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to wipe it dry. Do not use any type of solvent, such as thinner and benzene, as they may damage the surface of the DVR unit. If using a chemical saturated cloth to clean the unit, follow that product’s instructions. -
Page 6: Explanation Of Graphical Symbols
WARNING TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY. CAUTION C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,... -
Page 7: Rack Mount Instructions
RACK MOUNT INSTRUCTIONS Elevated Operating Ambient – If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature (Tma) specified by the manufacturer. - Page 8 CE NOTICE This product is in conformity with the following European Directives: ELECTROMAGNETIC COMPATIBILITY DIRECTIVE, 89/336/EEC (as amended by 92/31/EECand by Article 5 of 93/68/EEC) per the provisions of: EN 55022:1994 EN 55024:1998 EN 61000-4-4:1995 EN 61000-3-2:1995 CISPR 24:1997 EN 61000-4-5:1995 EN 61000-3-3:1995 EN 61000-4-2:1995 EN 61000-4-6:1995...
-
Page 9: Statement Of Limited Warranty
Statement of Limited Warranty Openeye warrants all new products to be free from defects in workmanship and material under normal use for a period of two years after the date of purchase. Any defective product that falls under this warranty will, at OpenEye's discretion, be repaired or replaced at no additional charge. - Page 10 28170A\C...
-
Page 11: Table Of Contents
Table of Contents PREFACE ..................................1 About this Guide ....................................1 Technician Notes ....................................1 INTRODUCTION ................................3 Product Description ................................... 3 Features ......................................4 Product Models ....................................4 CONTROLS AND CONNECTIONS ..........................7 System Specifications ..................................7 Front Panel Controls and LEDs ................................. 7 Rear Panel Connectors .................................. - Page 12 28170A\C...
-
Page 13: Preface
Only authorized personnel should attempt to repair this unit. OpenEye reserves the right to make changes to the DVR units represented by this manual without notice. The following text and symbols mark special messages throughout this guide: NOTE: Text set off in this manner indicates topics of interests that can help the user understand the product better. - Page 14 28170A\C...
-
Page 15: Introduction
PRODUCT DESCRIPTION An OpenEye X-Series 4 Channel DVR is simply a server that performs as a High Definition Digital Recorder. By utilizing the many features of a computer, including processing power, storage capacity, graphics compression, and security features, the DVR unit is more powerful than the analog recorders of the past. -
Page 16: Features
720 × 576,x720 × 288, 360 × 288 PAL PRODUCT MODELS OpenEye X-Series DVRs are available as both Real-Time and Non-Real Time display units. Real-Time Units are systems with 240 PPS recording capability and 16ch120R or 4ch120 specialty systems. Users can adjust the recording resolution of real-time units independently for each camera. - Page 17 28170AB...
- Page 18 28170A\C...
-
Page 19: Controls And Connections
SYSTEM SPECIFICATIONS OpenEye’s state-of-the-art High Definition Digital Recorders are housed in a high performance and versatile 3U Rack-Mount case allowing easy storage of multiple DVRs for enterprise applications. Every OpenEye DVR unit comes equipped with the latest technology: Intel® 3.2 Ghz Celeron D Processor... -
Page 20: Rear Panel Connectors
REAR PANEL CONNECTORS The rear panel of the DVR unit contains the connectors used to attach cameras, sensors, and relays to the DVR. The diagram below outlines the location and description of each connector. Audio / Spot Monitor Output BNC Connectors for Video Input 5.1 Surround Sound AC Power Connector RJ-45 Network Jack... - Page 21 28170AB...
-
Page 22: Getting Started
IDENTIFYING INCLUDED COMPONENTS OpenEye DVRs come with a mouse, keyboard and selected software and cables. Identify the following components to make sure everything has been properly included with the new DVR unit. If any of the following items are missing, contact the dealer to arrange a replacement. -
Page 23: Keyboard Setup
KEYBOARD SETUP To attach the keyboard to the DVR unit, plug the end of the Keyboard into the keyboard PS/2 Port located on the back of the machine. The keyboard PS/2 Port can be identified by the purple color. Refer to the Rear Panel Connectors diagram for more information. MOUSE SETUP To attach the mouse to the DVR unit, plug the end of the mouse into the mouse PS/2 Port located on the back of the machine. -
Page 24: Monitor Setup
MONITOR SETUP The DVR has the following connection available to attach a monitor. SVGA Output To VGA Monitor. Attach the monitor or monitors to the rear of the DVR unit using the cable supplied by the monitor manufacturer. Refer to the monitor manual for detailed information on how to setup and use it. -
Page 25: Connecting A Video Source To The Dvr
CONNECTING A VIDEO SOURCE TO THE DVR There are different types of Video Sources that can be plugged into the DVR unit including DVD players, VHS players, and CCTV Cameras. The back of the DVR unit has 4 video inputs. The connectors use the BNC standard. Channel 1 Channel 2 Channel 3... -
Page 26: Connecting Control Outputs To The Dvr
CONNECTING CONTROL OUTPUTS TO THE DVR Each DVR unit has 4 Control Outputs. These outputs can be used to trigger devices such as Sirens, Phone Dialers, Lights, and any other relay activated device. There is no power supplied to the ports. Use an external power supply if necessary. Siren, Alarm, Outside Relays (Common) External Po... -
Page 27: Connecting A Ptz Camera
CONNECTING A PTZ CAMERA Setting up a PTZ Camera is simple. The DVR unit comes preassembled with an internal PTZ adapter. The cabling may be run up to 4,000 ft using 22 Gauge Twisted Pair. It is important to understand how the PTZ connects to the DVR. The DVR outputs an RS-232 signal and converts in to an RS-485 signal which is then sent to the PTZ camera. -
Page 28: Turning On The Dvr
If asked to respond to the messages (adding a Printer, Monitor, etc for the first time) follow the instructions carefully. Startup is complete when the OpenEye DVR software finishes loading and displays the main menu screen. TURNING OFF THE DVR Click the Exit button on the main screen of the DVR software.
