- Page 1 Hybrid Video Recorder Hardware Manual H-Series XR-Series X-Series OE4-H4U48016 OE4-XR48032 OE4-X24016 OE4-H4U48008 OE4-XR48016 OE4-X24008 OE4-XR24032 OE4-X24016E OE4-XR24016 OE4-X12016 OE4-XR24008 OE4-X12008 OE4-X12004 www.openeye.net...
- Page 3 No part of this document may be reproduced by any means, electronic or mechanical, for any purpose, except as expressed in the Software License Agreement. OPENEYE shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is subject to change without notice.
-
Page 4: Important Safeguards
This will prevent damage to the product due to lightning and power line surges. Object and Liquid Entry Points – Never insert foreign objects into the HVR, other than the media types approved by OpenEye, as they may touch dangerous voltage points or short-out parts that could result in a fire or electrical shock. Never spill liquid of any kind on the product. -
Page 5: Notes On Handling
IMPORTANT SAFEGUARDS, continued Damage Requiring Service – Unplug the unit from the outlet and refer servicing to qualified service personnel under the following conditions: When the power-supply cord or plug is damaged. If liquid has been spilled, or objects have fallen into the unit. If the unit has been exposed to rain or water. - Page 6 NOTES ON CLEANING Use a soft dry cloth for cleaning. For stubborn dirt, soak the cloth in a weak detergent solution, wring well and wipe. Use a dry cloth to wipe it dry. Do not use any type of solvent, such as thinner and benzene, as they may damage the surface of the HVR. If using a chemical saturated cloth to clean the unit, follow that product’s instructions.
- Page 7 WARNING TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY. CAUTION C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,...
-
Page 8: Fcc Statement
RACK MOUNT INSTRUCTIONS Elevated Operating Ambient – If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature (Tma) specified by the manufacturer. -
Page 9: Standard Warranty
Standard Warranty OpenEye warrants all new products to be free from defects in workmanship and material under normal use for a period of two years after the date of purchase. Any defective product that falls under this warranty will, at OpenEye's discretion, be repaired or replaced at no additional charge. -
Page 11: Table Of Contents
Table of Contents PREFACE ..................................1 About this Guide ................................ 1 Technician Notes ............................... 1 INTRODUCTION ................................3 Product Description ..............................3 Features ..................................4 Product Models ................................. 4 CONTROLS AND CONNECTIONS ..........................5 ... - Page 12 Attaching the 4-Pin Adapter (240 & 480 H.264 models) ................19 Making Connections on an X-Series HVR ....................... 20 Connecting a Video Source ..........................20 4 Channel HVR .............................. 20 8 Channel HVR .............................. 20 ...
-
Page 13: Preface
TECHNICIAN NOTES Warning Only authorized technicians trained by OpenEye should attempt to repair this HVR. All troubleshooting and repair procedures that may be shown are for reference and minor repair only. Because of the complexity of the individual components and subassemblies, no one should attempt to make repairs at the component level or to make modifications to any printed wiring board. - Page 14 NOTES:...
-
Page 15: Introduction
HVR is more powerful than the analog recorders of the past. The OpenEye HVR server software comes pre-configured for fast and seamless integration within your existing IT infrastructure. Designed around Microsoft ®... -
Page 16: Features
OpenEye X -Series HVRs are available as Real-Time units. OpenEye X-Series HVRs are available as Real-Time and Non-Real Time display units. Real-Time Units are systems with 120R, 240 and 480 IPS recording capabilities. Users can adjust the recording resolution of real- time units independently for each camera. -
Page 17: Controls And Connections
CONTROLS AND CONNECTIONS FRONT PANEL CONTROLS AND LEDS The front panel of the HVR contains the devices that will be commonly used for data removal, retrieval, and backup replacement. The most common components and buttons are shown below: XR-SERIES FRONT PANEL Hard Drive Power Buttons Reset Button Power Switch... -
Page 18: Rear Panel Connectors
REAR PANEL CONNECTORS The rear panel of the HVR contains the connectors used to attach cameras, sensors, and relays to the HVR. Below are diagrams that outline the location and description of each connector: XR-SERIES REAR PANEL 8/16 Channel HVR Control Alarm Outputs BNC Connectors for Video Input / Looping Output Sensor Inputs... -
Page 19: Channel Hvr
32 Channel HVR 16 CH Cable Adapters/Looping Outputs* Control Alarm Outputs BNC Connectors for Video Input Looping Termination Switch Sensor Inputs CH 1 in CH 2 in CH 3 in CH 4 in CH 5 in CH 6 in CH 7 in CH 8 in CH 9 in CH 10 in... -
Page 20: X-Series Rear Panel
X-SERIES REAR PANEL 4 Channel RJ-45 Network Jack Audio/Spot Monitor Output SVGA Output BNC Connectors for Video Input AC Power Connector Cooling Fan RS-422 Interface PS/2 Mouse Input Sensors & Control Outputs Audio PS/2 Keyboard Input • Line In – line level USB Ports DVI-D •... -
Page 21: Channel (240E)
16 Channel (240E) AC Power Connector Adapter for BNC Looping Output Cable BNC Connectors for Video Input Looping Output Termination Sensors Inputs Control Outputs Cooling Fan RCA Video Out RS-485 Interface Network Port PS/2 Mouse Input Audio PS/2 Keyboard Input USB Ports •... -
Page 22: Pci Slot Configurations
PCI SLOT CONFIGURATIONS 120R IPS PCI Configuration RCA Video Out Audio Inputs DB-9 Serial Input RS-485 Interface 240 IPS 8/16 Channel PCI Configuration RCA Video Out DB-9 Serial Input RS-485 Interface Audio Inputs 240 IPS 32 Channel PCI Configuration RCA Video Out DB-9 Serial Input Audio Inputs RS-485 Interface... -
Page 23: 480 Ips 16 Channel Pci Configuration
480 IPS 16 Channel PCI Configuration RCA Video Out SVGA Monitor Output DB-9 Serial Input DVI Output RS-485 Interface Audio Input Cable Adapter 480 IPS 32 Channel PCI Configuration SVGA Monitor Output RCA Video Out DVI Output DB-9 Serial Input RS-485 Interface Audio Inputs 29060AB... -
Page 24: 240 Ips 8 Channel
H.264 240 IPS 8 Channel RCA Video Out DB-9 Serial Input RS-485 Interface Audio Input Cable Adapter H.264 480 IPS 16 Channel RCA Video Out DB-9 Serial Input RS-485 Interface Audio Input Cable Adapter... -
Page 25: Getting Started
IDENTIFYING INCLUDED COMPONENTS OpenEye HVRs come with a mouse, keyboard and selected software and cables. Identify the following components to make sure everything has been properly included with the new HVR. If any of the following items are missing, contact the dealer to arrange a replacement. -
Page 26: Keyboard Setup
KEYBOARD SETUP To attach the keyboard to the HVR, plug the end of the Keyboard into the keyboard PS/2 Port located on the back of the machine. The keyboard PS/2 Port can be identified by the purple color. Refer to the Rear Panel Connectors diagram for more information. MOUSE SETUP To attach the mouse to the HVR, plug the end of the mouse into the mouse PS/2 Port located on the back of the machine. -
Page 27: Monitor Setup
MONITOR SETUP The HVR has the following connections available to attach a monitor. SVGA Output To VGA Monitor DVI-D Output To Digital Display Attach the monitor or monitors to the rear of the HVR using the cable supplied by the monitor manufacturer. Refer to the monitor manual for detailed information on how to setup and use it. -
Page 28: Making Connections On An Xr-Series Hvr
MAKING CONNECTIONS ON AN XR-SERIES HVR CONNECTING A VIDEO SOURCE There are different types of Video Sources that can be plugged into the HVR including DVD players, VHS players, and CCTV Cameras. The back of the HVR contains up to 16 video inputs depending on the HVR model. The connectors use the BNC standard. 8 Channel HVR CH 1 in CH 2 in... -
Page 29: Connecting Sensors To The Hvr
CONNECTING SENSORS TO THE HVR Each HVR has up to 16 Sensor inputs. These inputs can be used with devices such as infrared devices, motion device, glass breakage alarms, door and window trips, and many more. The Sensors can be set to Normally Open or Normally Closed inside the software. -
Page 30: Looping Outputs
LOOPING OUTPUTS The 8/16 Channel Xr-Series HVR has up to 16 looping outputs. Depending on the destination of the looping outputs, each one may have to be terminated. CH 1 in CH 2 in CH 3 in CH 4 in CH 5 in CH 6 in CH 7 in... -
Page 31: Connecting A Ptz Camera
This is normally done utilizing a dip-switch configuration method on the addressable dome. OpenEye recommends that the ID of the camera coincide to the input number on the HVR. This will make future troubleshooting and configuration less complex. -
Page 32: Making Connections On An X-Series Hvr
MAKING CONNECTIONS ON AN X-SERIES HVR CONNECTING A VIDEO SOURCE There are different types of Video Sources that can be plugged into the HVR including DVD players, VHS players, and CCTV Cameras. The back of the HVR contains up to 16 video inputs depending on the HVR model. The connectors use the BNC standard. 4 Channel HVR Channel 1 Channel 2... -
Page 33: Connecting Sensors To The Hvr
CONNECTING SENSORS TO THE HVR Each HVR unit may have up to 16 Sensor inputs. These inputs can be used with devices such as infrared devices, motion device, glass breakage alarms, door and window trips, and many more. The Sensors can be set to Normally Open or Normally Closed inside the software. -
Page 34: Connecting Control Outputs To The Hvr
CONNECTING CONTROL OUTPUTS TO THE HVR Each HVR unit may have up to 4 Control Outputs. These outputs can be used to trigger devices such as Sirens, Phone Dialers, Lights, and any other relay activated device. There is no power supplied to the ports. Use an external power supply if necessary. 8/16 Channel Siren, Alarm, Outside Relays External Power Supply (DC 12V) -
Page 35: Looping Outputs
LOOPING OUTPUTS The 8/16 Channel HVR unit may have up to 16 Looping outputs. Depending on the destination of the outputs, each output may have to be terminated. The outputs are located on the BNC Connector Cable. Attach the cable to the input for the BNC Connector Cable highlighted below. -
Page 36: Connecting A Ptz Camera
This is normally done utilizing a dip-switch configuration method on the addressable dome. OpenEye recommends that the ID of the camera coincide to the input number on the HVR. This will make future troubleshooting and configuration less complex. -
Page 37: Hard Drive Array (Xr-Series Only)
HARD DRIVE ARRAY (XR-SERIES ONLY) Hard drives in the X -Series HVR are arranged left to right in the HDD cage. A minimum of one and a maximum of five hard drives may be installed in the hard drive cage. The hard drive installed in bay one contains the operating system and if removed will render the HVR inoperable. -
Page 38: Turning On The Hvr
If asked to respond to the messages (adding a Printer, Monitor, etc for the first time) follow the instructions carefully. Startup is complete when the OpenEye HVR software is finished loading and displays the main menu screen. TURNING OFF THE HVR Click the Exit Button on the main menu screen of the HVR software. -
Page 39: Technical Specifications
TECHNICAL SPECIFICATIONS XR-SERIES HVR 240H 480H Video Format NTSC/PAL Video Inputs (BNC) DVI-D x 1, SVGA x 1 (Primary Display), RCA x 1 (Spot Monitor) Video Outputs RCA x4 (480IPS model only) Looping Outputs (BNC) 240 IPS 360×240 480 IPS 360×240 480 IPS 360×240 Recording Rate 120 IPS 720×240... -
Page 40: X-Series Hvr
X-SERIES HVR 4CH 120IPS 16CH 240EIPS 16CH 240IPS Video Format NTSC/PAL Video Inputs (BNC) Video Outputs DVI-D x 1, SVGA x 1 (Primary Display), RCA x 1 (Spot Monitor) Looping Outputs (BNC) 120 IPS 360×240 240 IPS 320×240 240 IPS 360×240 Recording Rate 120 IPS 720×240 120 IPS 640×240... - Page 41 29060AB...
