OpenEye EasyDVR Quick Start Manual

EASYDVR
POWER Press and hold
this key to trigger the quick IR Receives infrared signal
shutdown function.
from the included remote
controller
NUMERIC
Live and Playback modes: Press any
key to view the corresponding video in
full-screen.
Input interface: 1~4 can be used for direct
input of numbers 1~4.
PTZ mode: Press 1 to enter the Set/ Go
preset menu.

Logging in for the First Time

User ID: admin
Password: 1234
Note After logging in for the first time, change the admin password for
the DVR and remote software to establish user level security. See
the User Manual for instructions.

How to Use the IR Remote Controller

When more than one OpenEye EasyDVR is installed in the same location,
you can use one remote controller to control up to 16 recorders. To
30726AA
REC Blinks when live video is recording.
NETWORK
Illuminates when
the recorder is connected to a
ALARM Blinks when an
network.
alarm is triggered.
PTZ Enter PTZ mode.
PLAY/STOP
Start/Stop playback.
BACKUP Open the
Backup menu and select
export options.
USB Connect a flash
drive for backup or USB
keyboard.
SEQ Trigger automatic
camera sequencing.
MENU Open the
configuration menu.
FREEZE Freeze the
current image in live or
playback mode.
DISPLAY Cycle
SEARCH Open the Search menu.
through the available
camera views.
control multiple recorders, you must change the remote controller ID to
match the Unit ID of the recorder. Follow the instructions below to set
the Unit ID and change the remote controller number.
Assign a unique Unit ID on the recorder
Press MENU on the front of the DVR or the Remote Controller.
1.
2. Select SYSTEM > RS485 Setup.
Enter the desired Unit ID number. See the Unit ID and Remote
3.
Control # table for reference.
Set the number on the Remote Controller
Press and hold the ID button on the remote controller and enter the
corresponding Remote Control number to operate the recorder.
4CH 120 IPS
H.264 DVR
ESC/LOCK Cancel a selection
or exit a menu.
ENTER
option or confirm a
selection.
DIRECTIONAL Navigate
menu items or change a
selected value.
For example, assuming the Unit ID is set to 225, press ID on the remote
controller and then press 2 immediately.
Unit ID and Remote Control #
To use the included remote controller, each recorder needs a unique
Unit ID number that corresponds with a Remote Control number. Use
the table below for reference.
Unit ID 224 225 226 227 228 229
Remote Control # 1 2 3 4 5
Unit ID 232 233 234 235 236 237
Remote Control #
9 10 11 12 13
Select a menu
230 231
6 7 8
238 239
14 15 16
