Compool Cp3810

System Power

IMPORTANT:
Switch back to
Auto after servicing equipment.
3 Hour Filter Override
When adding chemicals, the filter
pump can be set to stay on for three
hours -or- stay off for three hours.
This overrides the programming of
the Cp3810 indoor controller on a
one-time basis. The same procedure
can be used on the other equipment
keys 1-6.
Auto Instructions:
Make sure the Auto/Service
▲
key is in the Auto position.
Filter Pump On:
P Press Filter key 2 times quickly.
Filter Pump Off:
Press Filter key 3 times quickly.
P
Override Verification:
Auto The Auto lamp will blink
during the 3-Hour Override.
To cancel:
▲ The 3-hour override can be
cancelled by switching to
Service Service, and then back to Auto.
Water Sensor
Sensor
Solar Sensor
Status
Freeze Sensor
Lamp ON indicates problem with the
sensor or wires leading to sensor.
Check connections and replace sensor
if necessary.
Lx3810
System Power provides power to the transformer.
• To wire System Power
1.
2.
3.
4.
Caution Incorrect wiring will cause permanent damage to the transformer.
Auto
▲
Service
Filter
P
Pump
1
2
3
4
5
6
B.wash B
Heater
Solar
At the Sub-panel, install a circuit breaker for System Power. The system draws less than 1
amp. Do not use a GFCI circuit breaker.
Run appropriate wires from the circuit breaker to the System Power terminal block.
For a 115 volt connection, connect to terminals 2 and 3.
For a 230 volt connection, connect to terminals 1 and 3.
SUB-PANEL
