Compool Cp3810
Manual configuration.

Telephone Module

The Telephone Module (model MOD-TELSPA) allows turning the spa or pool on/off from a
phone.
• To install the Telephone Module
1.
1.
2.

Dimmer Relay

A maximum of two Dimmer Relays (model RLY-DIM) can be installed. These relays are
controlled by Equipment keys 3 and 4. Each relay can switch a maximum of 1000 watts.
• To install the Dimmer Relay
1.
2.
3.

Backwash Control

The backwash control system is designed to automatically backwash the filter on a timed basis.
This feature uses the B/W circuit to control the two backwash valves.
To install an automatic backwash system, you must have a sand filter with a side inlet and outlet.
The following additional equipment is required, a Valve Module (model MOD-VLV3), two
Valve Actuators (model CVA-24T), and two 3-port valves (model PTV-2T).
• To install the Backwash Control
1.
2.
3.
during these conditions, it is necessary to adjust the HI SPD program switch, which is
located at bottom of the Power Center circuit board.
Connect RLY-LXD relay control wire into 2SPD relay socket.
The system will run the filter pump in "low speed" during normal filter operation, but will
switch the pump to "high speed" when the selected auxiliary circuit is activated.
Select an auxiliary circuit (AUX1 - AUX6), and connect RLY-LXD control wire into the
appropriate relay socket.
Install the Telephone Module into the low voltage compartment of the Power Center.
Run a phone line to the Telephone Module.
Connect the 4-wire interface cable from the Telephone Module into the PHONE socket at
the bottom of the Power Center circuit board.
Install the Dimmer Relay(s) into high the voltage compartment.
Plug the control wire(s) into DIMMER 3 and/or DIMMER 4 sockets.
Turn on SPEC FNCT configuration switch DIM3 and/or DIM4 located at bottom of the
Power Center circuit board.
Connect a jumper wire between the B/W socket and the Valve Module CONTROL
JUMPERS socket. Turn on D.I.P. switch number 1 on the Valve Module.
Connect backwash Valve Actuator cords into VLV1 and VLV2 sockets on the Valve
Module.
Turn on SPEC FNCT configuration switch B/W located at the bottom of the Power Center
circuit board.
