22
4.
Floor Cleaner Valve
The Floor Cleaner Valve is designed to control a dual zone floor cleaning system. The Floor
Cleaner Valve can be programmed to rotate once every 1-99 minutes while the filter pump is
on. Additional parts required, one Valve Actuator (model CVA-24T) and one 3-port valve
(model PTV-2T).
•
To install the Floor Cleaner Valve
1.
2.
3.
4.
5.
Program the backwash interval and duration times at the Control Panel. See Calibration
for details.
Install Valve Actuator onto Floor Cleaner valve.
Plug valve actuator cord into AUX VLV socket on Power Center circuit board.
Connect a jumper wire between the AUX VLV CNTRL and the FLRCL sockets.
Turn on SPEC FNCT configuration switch FLRCL located at the bottom of Power Center
circuit board.
Program the time interval at the Control Panel. See Calibration for details.
Compool Cp3810
