Creating Pptp Or L2Tp Wan Connection - D-Link User ManualDIR-620 User Manual

DIR-620 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in Switch
User Manual

Creating PPTP or L2TP WAN Connection

To create a connection of the PPTP or L2TP type, click the Add button on the Net / WAN page. On
the opened page, select the relevant value from the Connection Type drop-down list and specify
the needed values.
Figure 89. The page for creating a new connection. The General settings section.
Parameter
Provider
Port
Name
Enable
Direction
General settings
Leave the Manually value.
Leave the auto value.
A name for connection for easier identification.
Select the checkbox to enable the connection.
The direction of this connection.
Page 107 of 202
Configuring via Web-based Interface
Description
