DIR-620 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in Switch
User Manual
Basic Settings
On the Wi-Fi / Basic settings page, you can configure basic parameters of the device's WLAN.
Parameter
Hide Access Point
SSID
Country
Channel
Wireless mode
Max Associated Clients
When you have configured the parameters, click the Change button.
Figure 106. Basic settings of the wireless LAN.
If the checkbox is selected, other users cannot see your Wi-Fi
network. (It is recommended not to select this checkbox in order to
simplify initial configuration of your WLAN.)
A name for the WLAN. By default, the value DIR-620 is specified.
It is recommended to specify another name for the network upon
initial configuration (use digits and Latin characters).
The country you are in. Select a value from the drop-down list.
The wireless channel number. When the auto value is selected, the
router itself chooses the channel with the least interference.
Operating mode of the wireless network of the router. This
parameter defines standards of the devices that will be able to use
your wireless network. Select a value from the drop-down list.
The maximum number of devices connected to the wireless network
of the router. When the value 0 is specified, the device does not limit
the number of connected clients.
Page 127 of 202
Configuring via Web-based Interface
