D-Link User ManualDIR-620 User Manual page 95

DIR-620 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in Switch
User Manual
Figure 78. The page for creating a new connection. The PPP section.
Parameter
Username
Without authorization
Password
Password confirmation
APN
Dial number
Authentication
algorithm
MTU
PPP
A username (login) to connect to the network of the operator.
Select the checkbox if your operator does not require authorization.
A password to connect to the network of the operator.
The confirmation of the entered password (to avoid mistypes).
An access point name. For GSM USB modems only.
A number dialed to connect to the authorization server of the
operator.
Select a required authentication method from the drop-down list or
leave the AUTO value.
The maximum size of units transmitted by the interface. Optional.
Page 95 of 202
Configuring via Web-based Interface
Description
