DIR-620 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in Switch
User Manual
Web-based Interface Structure
After successful registration the router's quick settings page opens.
The web-based interface of the router is multilingual. Select a needed language from the menu
displayed when the mouse pointer is over the Language caption. You can change the language of
the web-based interface in any menu item.
After selecting the language, the notification on unsaved changes will be displayed. Click the Save
icon (
) to save the current language of the web-based interface as the default language.
The quick settings page displays general information on the router and its software (the version and
the date of the firmware, the IP address of the device, the name of the WLAN, etc.).
Figure 18. The quick settings page.
Figure 19. Changing the language of the web-based interface.
Page 29 of 202
