Creating 3G WAN Connection

If the PIN code check is enabled for the SIM card inserted into your USB modem, then prior to
creating a 3G WAN connection, proceed to the USB modem menu and enter the PIN code on the
page displayed (see the USB Modem section, page 169). Then proceed to the Net / WAN page,
click the Add button, and select the 3G value from the Connection Type drop-down list.
Figure 77. The page for creating a new connection. The General settings and 3G sections.
Parameter
Provider
Port
Name
Enable
Direction
Mode
General settings
To automatically specify all settings required to connect to the
Internet, select your country and operator from the drop-down list.
To specify all settings independently, leave the Manually value.
Select the USB value.
A name for connection for easier identification.
Select the checkbox to enable the connection.
The direction of this connection.
3G
The value of the field specifies the type of the network to which the
router connects. Leave the auto value to let the router connect
automatically to an available type of network, or select a needed
value from the drop-down list. For GSM USB modems only.
Page 94 of 202
Configuring via Web-based Interface
Description
