D-Link User ManualDIR-620 User Manual page 69

DIR-620 Multifunction Wireless Router Supporting WiMAX,
3G GSM/CDMA with Built-in Switch
User Manual
Figure 55. Configuring PPTP + Dynamic IP WAN connection. The expert settings mode. The VPN section.
Parameter
Connection name
Connect automatically
Username
Without authorization
Password
Password confirmation
VPN server address
A name for connection for easier identification.
VPN
Select the checkbox to enable auto-start of the connection upon the
boot-up of the router.
A username (login) to access the Internet.
Select the checkbox if you don't need to enter a username and
password to access the Internet.
A password to access the Internet.
The confirmation of the entered password (to avoid mistypes).
The IP or URL address of the PPTP or L2TP authentication server.
Page 69 of 202
Configuring via Web-based Interface
Description
