HARDWARE FEATURES
2.1
xPC56XXMB Board Features
4
•
ON/OFF Power Switch w/ LED indicators
•
A 12VDC power supply input barrel connector
•
Onboard ST Microelectronics L9758 regulator provides three different
power voltages simultaneously: 5V, 3.3V, and 1.2V
•
Onboard peripherals can be configured to operate at 5V or 3.3V logic
levels
•
Two CAN channels with jumper enables
•
One CAN channel with High-Speed transceiver and DB9 male
connector
•
One CAN channel with Low-Speed Fault Tolerant and High-
Speed transceiver (selectable with jumpers) and DB9 male
connector
•
Two LIN channels with jumper enables
•
One channel with transceiver and pin header connector
populated
•
One channel with footprints only
•
One SCI channel with jumper enables
•
Transceiver with DB9 female connector
•
Two FlexRay channels with jumper enables
•
One channel with transceiver and DB9 male connector
•
One channel with footprint only
•
Four user push buttons with jumper enables and polarity selection
•
Four user LED's with jumper enables
•
One potentiometer for analog voltage input
•
Pin array for accessing all I/O signals
•
Expansion connectors for accessing all I/O signals
•
Development zone with 0.1" spacing and SOIC footprint prototyping
