J6 – LIN1 pin2 configuration
Jumper Setting
On
Off (default)
J22 – LIN1 enable
Jumper Setting
On (default)
Off
J23 – LIN1 master selection
Jumper Setting
On
Off (default)
J24 – LIN1 pin1 configuration
Jumper Setting
14
Effect
Pin 2 of the LIN1 connector is connected to 12V
Pin 2 of the LIN1 connector is not connected to 12V
Effect
Enables the LIN1 transceiver
Disables the LIN1 transceiver
Effect
LIN1 is configured as a master node
LIN1 is configured as a slave node
Effect
xPC56XXMB User Manual
