J31 – LIN2 pin2 configuration
Jumper Setting
On
Off (default)
J19 – LIN2 enable
Jumper Setting
On
Off (default)
16
Figure 3-4: LIN1 Schematic
Effect
Pin 2 of the LIN2 connector is connected to 12V
Pin 2 of the LIN2 connector is not connected to 12V
Effect
Enables the LIN2 transceiver
Disables the LIN2 transceiver
xPC56XXMB User Manual
