J36 – VIO Peripherals Logic Level
Jumper Setting
1+2
2+3 (default)
J37 – VBat low voltage detection
Jumper Setting
On
Off (default)
xPC56XXMB User Manual
Effect
Onboard peripherals are configured for 3.3V logic
Onboard peripherals are configured for 5V logic
Effect
Low battery detection is enabled
Low battery detection is disabled
