Package Contents; Supported Devices; Recommended Materials - P&E Microcomputer Systems xPC56XXMB User Manual

1.1

Package Contents

An xPC56XXMB Evaluation Kit includes the following items:
1.2

Supported Devices

To work with a specific device in the MPC56xx family of microprocessors, the
correct Mini-Module (not included) must be used to plug into the xPC56XXMB
motherboard. Below is a list of all available Mini-Modules and their supported
devices:
xPC560BADPT100S Mini-Module: Supports MPC5604BEMLL
xPC560BADPT144S Mini-Module: Supports MPC5604BEMLQ
xPC560BADPT208S Mini-Module: Supports MPC5604BEMMG
xPC560PADPT100S Mini-Module: Supports MPC5604PEFMLL
xPC560PADPT144S Mini-Module: Supports MPC5604PEFMLQ
xPC560SADPT144S Mini-Module: Supports MPC5606SEMLQ
xPC560SADPT176S Mini-Module: Supports MPC5606SEMLU
xPC560SADPT208S Mini-Module: Supports MPC5606SEMMG
xPC563MADPT144S Mini-Module: Supports MPC5633MMLQ80
xPC563MADPT208S Mini-Module: Supports MPC5633MMMG80
1.3

Recommended Materials

2
• One xPC56XXMB Motherboard
• One xPC56XX Resources CD-ROM
• Freescale Warranty Card
• Freescale device reference manual and datasheet
• xPC56XXMB schematic
• Mini-Module hardware manual and schematics
xPC56XXMB User Manual
