P&E Microcomputer Systems xPC56XXMB User Manual page 29

7+8 (default
on)
J34 & J35 FlexRay 1 Terminal Resistor Connection
Jumper Setting
On
Off (default)
J32 – FlexRay Bus Driver 2 Enable
Controls which I/O pins on the processor are connected to the TxD and RxD
pins on FlexRay Bus Driver. The exact pins used are dependent on the
specific Mini-Module plugged into the motherboard. Please refer to the Mini-
Module hardware manual for more details.
Jumper Setting
1+2
3+4
5+6
J33 – FlexRay Bus Driver 2 Pull‐up Enable
xPC56XXMB User Manual
The WAKE pin on the FlexRay Bus Driver is pulled up
to 5V
Effect
Terminal resistors connected
Terminal resistors not connected
Effect
The TXD pin on the FlexRay Bus Driver is connected
to a processor I/O pin.
The TXEN pin on the FlexRay Bus Driver is connected
to a processor I/O pin.
The RXD pin on the FlexRay Bus Driver is connected
to a processor I/O pin.
25
