On
Off (default)
J11 – CAN (L) TxD/RxD Enable
Controls which I/O pins on the processor are connected to the TxD and RxD
pins on CAN (L). The exact pins used are dependent on the specific Mini-
Module plugged into the motherboard. Please refer to the Mini-Module
hardware manual for more details.
Jumper Setting
1+3
3+5 (default)
2+4
4+6 (default)
22
Enables CAN transmission
Disables CAN transmission
Effect
The RxD pin of the CAN (L) interface is connected to a
processor I/O pin.
The RxD pin of the CAN (L) interface is connected to a
processor I/O pin.
The TxD pin of the CAN (L) interface is connected to a
processor I/O pin.
The TxD pin of the CAN (L) interface is connected to a
processor I/O pin.
xPC56XXMB User Manual
