- Page 1 OPERATIONS MANUAL & PARTS LIST Fastracts Extractor IPC Eagle • 3650 Dodd Rd, Eagan MN 55123 • 800.486.2775 • www.ipceagle.com...
-
Page 2: Before Operating The Machine
Keep this manual handy at all times. This machine will assure years of satisfactory service if operated and maintained according to recommendations in this manual. If additional information is needed, please contact your local distributor or write to: IPC Eagle 3650 Dodd Rd Eagan, MN 55123 WARNING •... -
Page 3: Preparing The Machine
PREPARING THE MACHINE 1. Unfasten the two latches which hold the recovery tank to the solution tank. Lift recovery tank off solution tank. 2. Pour clean solution into the solution tank. 3. Replace the recovery tank onto the solution tank and fasten the two latches. 4. -
Page 4: Periodic Maintenance
PERIODIC MAINTENANCE All Eagle Power machines are engineered and built to require a minimum of maintenance. But like any machine, it does require some care to keep it in optimum working condition. Careful attention to these maintenance instructions will give you maximum operating performance and will increase the life expectancy of your machine. - Page 5 Fastracts BX2 PARTS DIAGRAM...
- Page 6 Fastracts BX2 PARTS LIST ITEM # PART # DESCRIPTION F11695-G HANDLE, BLUE F11694-G CORD WRAP C00314-1 HEX BOLT, 1/4-20 X I C00233 WASHER, 1/4" FLAT F11696-G RECOVERY TANK D11692 LATCH W/STRIKER C00310-12 SCREW, 8-32 X 1/2" E11044 GASKET, 2.25 OD E11045 FOAM DISC, 1.5 OD 1/2 THICK D11043...
- Page 7 Fastracts BX2 PARTS LIST ITEM # PART # DESCRIPTION QTY. G11688 WHEEL, 6" E10521 GASKET, VACUUM MOTOR C11702 HEX NUT, 3/8 16 A00130 ELBOW, 1 /8 MP X 1 /4 B D11684 INLET FILTER A00152 TEE, 1/8 MP X 1/8 FP X 1/8 FP A00139 1/4 MP X 1/4 BARB, BRASS C00232...
-
Page 8: Warranty Policy
Date Purchased: Model Number: Serial Number: Please be sure to record this information. This information will be necessary for future warranty claims. IPC Eagle Products Sales and Service Provided by: 3650 Dodd Rd, Eagan, MN 55123 651.686.5399 Fax 651.686.5695 www.ipceagle.com...
