Page 1: Parts List
OPERATIONS MANUAL & PARTS LIST BX12, BX12H Fastracts Extractor IPC Eagle • 3650 Dodd Rd, Eagan MN 55123 • 800.486.2775 • www.ipceagle.com... -
Page 2: Before Operating The Machine
Keep this manual handy at all times. This machine will assure years of satisfactory service if operated and maintained according to recommendations in this manual. If additional information is needed, please contact your local distributor or write to: IPC EAGLE 3650 Dodd Rd. Eagan, MN 55123 WARNING •... -
Page 3: Grounding Instructions
GROUNDING INSTRUCTIONS The120V A/C and the 220V A/C models have been outfitted with the appropriate grounded connectors. Make sure the machine is connected to a grounded outlet having the same configuration as the grounded plug. No adapter should be used with this machine. Any modification to the connectors will void the warranty. PREPARING THE MACHINE (ALL FASTRACT EQUIPMENT) IMPORTANT: For all FASTRACT equipment, use only the correct IPC high pressure, high heat wands &... -
Page 4: Cleaning Upholstery
OPERATING INSTRUCTIONS- CARPET TOOL 1) Turn on the vacuum and solution switches. Slowly pull the tool towards you with the solution valve trigger engaged. Then make a pass forward and backward with the vacuum only (no spray) over the cleaned area to remove as much dirt and solution as possible. Do not overwet carpet! Make overlapping passes to prevent streaking. -
Page 5: Daily Maintenance
DAILY MAINTENANCE 1) Always keep the machine clean inside and out. 2) Pour 2 gallons of clean hot water in the solution tank. Turn on and flush the entire system through the wand nozzles for about a minute to prevent build-up. 3) Remove dirt and lint build-up inside the filter screen in the recover tank. - Page 6 11 12 13 14 15 BX12 Upper...
- Page 7 BX12 (UPPER) ITEM # PART # DESCRIPTION F11275 SOLUTION TANK F11138 RECOVERY TANK F11137 LID, SOLUTION TANK E11124 GASKET, RECOVERY TANK 12904A STAND PIPE ASSEMBLY K11965 ELBOW, 180º FLOAT BALL K00672 PVC PIPE, 1.5 X 12 IN, SCH 40 WHITE...
- Page 8 20 21 BX12 Base...
- Page 9 BX12 (BASE) ITEM # PART # DESCRIPTION C00297 SCREW, #8 X .25 IN, PAN HEAD J11863 HOSE, 3 IN J00639 SCREW CLAMP, 1.63-2.43 IN J00618 VACUUM HOSE, 2 IN GRAY, WIRE, 22 IN LG F11178-BLK INTERCOOLER, BLACK C00273 LOCKNUT, 1-4 X 20, NYLON, SS C00233 WASHER, FLAT, .25 IN...
