fi regear Outdoors Key West
Outdoor Decorative Gas Appliances
WARNING:
If the information in these instructions
are not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Installation and service must be
performed by a qualifi ed installer,
service agency or the gas supplier
Tested by:
FIREGEAR OUTDOORS OUTDOORS A DIVISION OF SKYTECH II INC. 9230 CONSERVATION WAY, FORT WAYNE, IN 46809
919-109b
WARNING - FOR YOUR SAFETY
What to do if you smell gas:
•Shut off gas to the appliance.
•Do not try to light any appliance.
•Extinguish any open fl ame.
•If odor continues, keep away from the appliance and im-
mediately call your gas supplier or fi re department.
•Do not touch any electrical switch: do not use any phone
in your building.
•Immediately call your gas supplier from a neighbour's
phone.
•Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fi re
department.
WARNING:
Do not store or use gasoline or other fl ammable vapours
and liquids in the vicinity of this or any other appliance.
A LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Series
™
WARNING: FOR OUTDOOR USE ONLY
Owners &
Installation Manual
MODELS: KWCH-1
KWDH-1
KWBH-1
02/25/13
Advertisement
Table of Contents
Related Manuals for Firegear Key West KWCH-1
Summary of Contents for Firegear Key West KWCH-1
- Page 1 Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 02/25/13 FIREGEAR OUTDOORS OUTDOORS A DIVISION OF SKYTECH II INC. 9230 CONSERVATION WAY, FORT WAYNE, IN 46809 919-109b...
- Page 2 To the New Owner: Congratulations! ® You are the owner of a state-of-the-art Outdoor Decorative Gas Appliance by fi regear Outdoors The Key West™ Series Outdoor Decorative Gas Appliance has been designed to provide you with all the warmth and charm of a fi re at the fl ick of a switch. The Key West™ Series Outdoor Decorative Gas Appliance has been approved by Warnock Hersey/Intertek for both safety and effi...
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY LABEL First Fire ..............30 Copy of Lighting Plate Instructions ......31 Maintenance Instructions..........32 Switch replacement .............33 Copy of Safety Decal .............4 Valve assembly replacement ........34 Digital fi replace control replacement ......35 DIMENSIONS Battery replacement ............35 PARTS Unit Dimensions - coffee Height ........5 Unit Dimensions - Dining Height........6 Parts ................36 Unit Dimensions - Bar Height ........7... -
Page 4: Safety Label
This is a copy of the label that accompanies each Outdoor decorative gas appliance. We have printed a copy of the contents here for your review. NOTE: Firegear Outdoors ® units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Dimensions
DIMENSIONS UNIT DIMENSIONS - COFFEE HEIGHT 48" (1219mm) 38" (965mm) 5-1/16" (129mm) TOP VIEW 5-5/8”(143mm) 38”(965mm) 2-9/16”(64mm) 11LB TANK 11LB TANK FLOOR LEVEL 16-11/16”(423mm) 40-5/8”(1030mm) 2-1/16”(52mm) END VIEW Floor to bottom SIDE VIEW of LP tank NOTE: Optional glass surround shown fi... -
Page 6: Unit Dimensions - Dining Height
DIMENSIONS UNIT DIMENSIONS - DINING HEIGHT 62" (1575mm) 14-1/4" (361mm) 12-3/16" (309mm) BURNER GLASS OUTER EDGE OUTER EDGE 36" (914mm) 1-5/8” (39mm) 6-3/16 ” (156mm) 28-7/8” (733mm) 1” 20lb tank 20lb tank (25mm) 40-3/8” 20-11/16” Floor level (1031mm) 3-1/8” (525mm) (79mm) Floor to NOTE: For optional glass surround dimensions - see previous page. -
Page 7: Unit Dimensions - Bar Height
DIMENSIONS UNIT DIMENSIONS - BAR HEIGHT 62" (1575mm) 14-1/4" (361mm) 12-3/16" (309mm) BURNER GLASS OUTER EDGE OUTER EDGE 36" 914mm TOP VIEW 16 " 16 " 963mm 325mm 8 " 4 " 1248mm 742mm SIDE VIEW END VIEW NOTE: Optional glass surround shown fi... -
Page 8: Important Message
INSTALLATION IMPORTANT MESSAGE DO NOT USE THIS APPLIANCE IF 5) DO NOT SIT OR STAND ON DECORATIVE SAVE THESE ANY PART HAS BEEN UNDER WATER. GAS APPLIANCE IMMEDIATELY CALL A QUALIFIED INSTRUCTIONS 6) To prevent injury, do not allow anyone who SERVICE TECHNICIAN TO INSPECT is unfamiliar with the operation to use the THE APPLIANCE AND TO REPLACE... -
Page 9: Installation Checklist
INSTALLATION LOCATING YOUR INSTALLATION OUTDOOR DECORATIVE GAS APPLIANCE CHECKLIST 1) When selecting a location for your outdoor decorative gas appliance, ensure that the clearances are 1) Appliance is factory equipped for Propane. When met. using Natural Gas, see NG conversion section in this manual. -
Page 10: Important Things To Remember
INSTALLATION IMPORTANT INFORMATION FOR OUTDOOR FIREPLACE INSTALLATIONS • Never insulate around the body of the unit IMPORTANT THINGS TO REMEMBER • Excessive heat retention in the fi rebox will lead to component failure • Correct Working Gas pressure is critical on “E” units and fi... -
Page 11: Minimum Clearances To Combustibles
INSTALLATION MINIMUM CLEARANCES TO COMBUSTIBLES The clearances listed below are Minimum distances unless otherwise stated: A major cause of fi res is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this decorative gas appliance be installed only in accordance with these instructions. -
Page 12: High Elevation
Max. Supply Pressure 14" WC (3.49 kpa) Note: If you have an incorrect fl ame pattern, Min. Supply Pressure 11" WC (2.73 kpa) ® contact your Firegear Outdoors dealer for further instructions. Manifold Pressure 10" WC (2.49 kpa) Manifold Pressure-Low 6.4"... -
Page 13: Wiring Diagram
INSTALLATION WIRING DIAGRAM This appliance does not require a 120V A.C. supply for operation. 0.886.001 Proflame Valve Standard Main On/Off Switch or Optional Wall Switch Important: The AA batteries in the battery pack operate the burner switch. If the batteries become weak they will need to be replaced with quality alka- line batteries. -
Page 14: Gas Connection
INSTALLATION GAS CONNECTION 1) Remove end panel (end with the ON/OFF switch). Panels are held in place 3) Connect gas line. by magnets. Place panel on a soft clean surface. Gas connection @ unit 4) Check all gas connections (both valve train & propane tank or NG source) under normal operating pressure, for leaks, with soapy water. -
Page 15: Conversion From Lp To Ng
INSTALLATION CONVERSION FROM LP TO NG THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 4) Remove burner orifi ce with a 1/2" wrench. Use another wrench to hold on Each Kit contains one NG Conversion Kit to the elbow behind the orifi... - Page 16 INSTALLATION 9) Remove end panel (panel w/ switch) from unit. 14) Remove LP gas line, if installed - replace with NG gas line and quick connection. Gas connection @ unit 15) Check all gas connections under normal operating pressure, for leaks, with soapy water.
-
Page 17: Lp Tank Installation - Kwch Only
INSTALLATION LP TANK INSTALLATION - KWCH ONLY NOTE: Max tank size 11lb. 1) Remove end panel (opposite end of switch panel),. 2) Remove long side panel (left panel if facing ON/OFF switch end), to ac- cess the 3/8" fi tting to the gas control. 5) Connect the LP regulator quick connect to the tank. -
Page 18: Lp Tank Installation
INSTALLATION LP TANK INSTALLATION LP TANK REMOVAL KWDH/KWBH ONLY NOTE: Max tank size 20lb. 1) Remove end panel (opposite end of switch panel). 1) Remove end panel (opposite end of switch panel). 2) Slide out LP gas tank by pulling from handle on slide out tray. 2) Ensure tank is fully closed. -
Page 19: Switch Connection
INSTALLATION SWITCH CONNECTION BATTERY INSTALL 1) Remove the end panel (side with switch assembly mounted on it) from unit. 1) Remove left side (with switch assembly) end panel from unit. 2) Pull down battery compartment - located below the DFC panel. Battery compartment 2) Connect 2 wires to the switch. -
Page 20: Table Top Installation - Coffee Height Unit
INSTALLATION TABLE TOP INSTALLATION - COFFEE HEIGHT UNIT Before installation,stainless steel must be handled and cleaned as per instructions noted below: Stainless Steel Table Top • Stainless table top must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for damage after installation will not receive consideration. -
Page 21: (For Dining And Bar Units Only)
INSTALLATION TABLE TOP INSTALLATION (FOR DINING AND BAR UNITS ONLY) 5) Install tiles - starting with 4 corner tiles. Table Top Components. Tiles Tiles (small inner) Filler Brackets. Table Top Frame Inner frame NOTE: TAKE CARE WHEN HANDLING AND INSTALLING TILES. TILES TO FREE FLOAT _ DO NOT GLUE TILES TO TABLE TOP. -
Page 22: Glass Crystal Installation
INSTALLATION FIREGLASS INSTALLATION Evenly spread the Fireglass or optional Ceramic Spa Stones over the burner. Ensure the crystals (or stones) do not overlap too much as this will effect the fl ame pattern. IMPORTANT NOTE: Only the supplied approved Fireglass are to be used with these fi replaces. Use of any other type of fi reglass can alter the unit's performance, any damage caused by the use of any unapproved glass will not be covered under warranty. -
Page 23: Optional Volcanic Stone Installation
INSTALLATION OPTIONAL VOLCANIC STONE INSTALLATION Evenly spread the fi reglass and volcanic stones over the burner. Ensure the stones do not overlap too much as this will effect the fl ame pattern. IMPORTANT NOTE: Only the supplied approved Volcanic Stones are to be used with these fi replaces. Use of any other type of stones can alter the unit's performance, any damage caused by the use of any unapproved glass or stones will not be covered under warranty. -
Page 24: Optional Twig Set Installation
INSTALLATION OPTIONAL TWIG SET INSTALLATION Read the instructions below carefully and refer to the images. If the logs are broken do not use the unit until they are replaced. Broken logs can interfere with pilot operation. Improper positioning of the logs may create carbon build-up and can alter the unit's performance which is not covered under warranty. - Page 25 INSTALLATION 4) Install log B on the left side of the burner as shown below. Orient log B in the same way and in a similar position as shown in Diagram 5. Diagram 5 5) Install log F on the burner as shown below. Orient log F across log A in the same way and in a similar position as shown in Diagram 6. Diagram 6 6) Install log C on the left side of the burner as shown below.
-
Page 26: Optional Glass Surround Installation
INSTALLATION OPTIONAL GLASS SURROUND INSTALLATION 1. Remove metal fasteners from the corner brackets. 4b. Use supplied spacer tool to determine where the bottom bracket should be placed and secured. 2. Assemble the 4 pieces of the glass surround and fasten together with Bottom Bracket 4 corner top brackets and supplied nylon fasteners as shown below. -
Page 27: Riser Installation
INSTALLATION RISER INSTALLATION (TO CONVERT DINING INTO BAR HEIGHT) A riser may be installed at the base of the dining table to convert it into a 5) Install the 4 adjustable rubber feet into the bottom of the dining riser. bar table. - Page 28 INSTALLATION 5) Install 12 screws in locations shown below to secure dining frame to riser base. 5) Reinstall LP tank and reconnect or reconnect NG gas line. Reinstall panels, table top and glass surround and fi reglass to complete installation. fi...
-
Page 29: Key West Table Cover Installations
INSTALLATION KEY WEST TABLE COVER INSTALLATIONS DINING LEAF GLASS SURROUND COVER For all units: For all units with glass surround installed: 1) Place the dining leaf cover over the burner of the unit when not in use. 1) Place the weather cover over the glass surround when not in use. WEATHER COVER For all units: 1) Place the weather cover over the entire table - when not in use. -
Page 30: Operating Instructions
OPERATING INSTRUCTIONS OPERATING FIRST FIRE INSTRUCTIONS The fi rst fi re in your decorative gas appliance is part of the paint curing process. To ensure that the paint 1) Read and understand these instructions before is properly cured, it is recommended that you burn operating this appliance. -
Page 31: Copy Of Lighting Plate Instructions
OPERATING INSTRUCTIONS INSTALLATION COPY OF LIGHTING PLATE INSTRUCTIONS The lighting plate is located on the underside of the front access panel in the unit. A) This appliance is equipped with an ignition device which automatically lights the pilot. FOR YOUR SAFETY READ BEFORE LIGHTING Do not try to light the pilot by hand. -
Page 32: Maintenance Instructions
MAINTENANCE MAINTENANCE INSTRUCTIONS 1) Always turn off the gas valve and unplug the batteries before cleaning. For relighting, refer to lighting instructions. Keep the burner and control compartment clean by brushing and vacuuming at least once a year. When cleaning the twigs, use a soft clean paint brush as the twigs are fragile and easily damaged. 2) Clean off leaves etc. -
Page 33: Switch Replacement
MAINTENANCE SWITCH REPLACEMENT 1) Remove the end panel (side with switch assembly mounted on it) from unit. 2) Remove 2 wire from the switch. 3) Remove 2 screws from switch cover to release switch. 4) Replace switch and reverse steps. fi... -
Page 34: Valve Assembly Replacement
MAINTENANCE VALVE ASSEMBLY REPLACEMENT Turn the unit off and allow to cool to room temperature. 8) Manuover valve assembly up and out. 1) Remove burner buy removing 6 screws in locations shown below. 2) Slide the burner to the left and lift out. 9) Replace gasket if required. -
Page 35: Digital Fi Replace Control Replacement
MAINTENANCE DIGITAL FIREPLACE CONTROL REPLACEMENT 4) Disconnect spark electrode wire. 1) Remove left side (with switch assembly) end panel from unit. Disconnect fl ame sensor (red) Disconnect ground. Disconnect wire harness. Ground Wire harness Spark Electrode Flame sensor 5) Remove 4 screws to remove DFC box. 6) Replace with new DFC box and reverse steps 5-1. -
Page 36: Parts
PARTS LIST PARTS Part # Description Part # Description 376-526 Burner Assembly LP/NG 946-775 *Firefi reglass - Blk 911-006 Pilot Assembly - NG 946-776 *Firefi reglass - Copper 911-007 Pilot Assembly - LP 946-777 *Firefi reglass -Starfi re 376-574/P Valve Assembly - NG 946-778 *Firefi... - Page 37 NOTES fi regear Key West™ Outdoor Gas Fireplace...
- Page 38 NOTES fi regear Key West™ Outdoor Gas Fireplace...
-
Page 39: Warranty
WARRANTY fi regear Outdoors products are designed with reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly before it leaves our facility. fi regear Outdoors is pleased to extend this limited warranty to the original purchaser of a fi regear Outdoors Product. This warranty is not transferable. Limited Warranty: The combustion chamber is covered for parts only, against defect in manufacture only, for a period of (5) fi... - Page 40 fi regear Outdoors® fi replaces are designed with reli- ability and simplicity in mind. In addition, our inter- nal Quality Assurance Team carefully inspects each unit thoroughly before it leaves our door. fi regear Outdoors is pleased to extend this Lim- ited Lifetime Warranty to the original purchaser of a fi...
