Outdoor Decorative Gas Appliance
WARNING:
If the information in these instructions
are not followed exactly, a fire
or explosion may result causing
property damage, personal injury or
loss of life.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property damage.
Read the installation, operating and
maintenance instructions thoroughly
before installing or servicing this
equipment.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
Tested by:
FIREGEAR OUTDOORS OUTDOORS A DIvISION OF SkYTEch II INc. 9230 cONSERvATION WAY, FORT WAYNE, IN 46809
919-137a
firegear Outdoors
Key West
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
KWB
™
WARNING - FOR YOUR SAFETY
What to do if you smell gas:
•Shut off gas to the appliance.
•Do not try to light any appliance.
•Extinguish any open flame.
•If odour continues, keep away from the appliance and im-
mediately call your gas supplier or fire department.
•Do not touch any electrical switch: do not use any phone
in your building.
•Immediately call your gas supplier from a neighbour's
phone.
•Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fire
department.
WARNING:
Do not store or use gasoline or other flammable vapours
and liquids in the vicinity of this or any other appliance.
Installation Manual
WArninG: FOr OutDOOr use Only
A DIVISION OF SKYTECH PRODUCTS GROUP
Owners &
MODELS: KWB-NG1
KWB-LP1
02/25/13
