SUPREME VOLCANO PLUS Owner's Manual

Installation and operation
Hide thumbs Also See for VOLCANO PLUS:
Table of Contents

Advertisement

Quick Links

FIREPLACE INSERT, MODEL
•
VOLCANO PLUS
Tested and certified to: by Intertek
• ULC S628-M93
• UL 1482-1996
OWNER'S MANUAL
- INSTALLATION
- OPERATION
Save These Instructions for Future Reference.
Manufactured by:
2G4
3594 Jarry East, Montreal, QC., H1Z
Phone: 1-877-593-4722
Fax: (514) 593-4424
www.supremem.com
info@supremem.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VOLCANO PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SUPREME VOLCANO PLUS

Summary of Contents for SUPREME VOLCANO PLUS

  • Page 1 FIREPLACE INSERT, MODEL • VOLCANO PLUS Tested and certified to: by Intertek • ULC S628-M93 • UL 1482-1996 OWNER’S MANUAL - INSTALLATION - OPERATION Save These Instructions for Future Reference. Manufactured by: 3594 Jarry East, Montreal, QC., H1Z Phone: 1-877-593-4722 Fax: (514) 593-4424 www.supremem.com...

  • Page 2: Warranty Limitations

    Inc. shall not be responsible for any labor costs. 3. From the sixth through the twenty-fifth year of the limited lifetime warranty, Supreme Fireplaces Inc., will provide replacement parts (if available) at 50 % of the retail price, except for the parts mentioned above in exclusions.
  • Page 3 Volcano Plus Revised June 2007 FOYER SUPREME, MODEL "VOLCANO PLUS" IMPORTANT Read all instructions carefully before installing and operating your fireplace insert and keep these instructions for future reference. Failure to follow these instructions could cause serious harm and property damage. Contact your local building or fire officials for restrictions and installation inspection requirements in your area.

  • Page 4: Minimum Clearances To Combustibles

    Volcano Plus Revised June 2007 MINIMUM CLEARANCES TO COMBUSTIBLES COMBUSTIBLE SIDE FACING COMBUSTIBLE MANTLE 8 MAX. 9 (NOTE) 36 1/2 NOTE: If T is bigger than 2 in., then 9 in. becomes 10 1/2 in. NON-COMBUSTIBLE FLOOR PROTECTOR FIGURE 1...

  • Page 5: Support Installation

    Volcano Plus Revised June 2007 PIECES REQUIRED VERIFICATION 1 Firebox Minimum size of the fireplace must be: 2 Fixing plate 3 Side support Depth 20 in. 4 Rear support Width 30 in. 5 Flexible liner 6 in. dia. or a combination of Height 23 in.

  • Page 6: Firebox Installation

    Important Note: The fireplace insert has been designed to be used with the door closed. The VOLCANO PLUS fireplace insert is designed to burn good quality, dry cordwood. The suggested length of a log is 18 in. and should preferably be in half or quarters. Excessive moisture content in firewood causes excessive creosote deposits in the chimney, which could lead to a chimney fire.

  • Page 7: Creosote Formation And The Need For Removal

    Fireplaces featuring conventional air controls require the user to open the control to the maximum to start the fire and later manually adjust it to the desired burn rate. With the Supreme automatic air control, the user establishes the burn rate of the fireplace once at the beginning of the season and should not alter the position of the control for the entire season.

  • Page 8: Starting The Fire

    Volcano Plus Revised June 2007 STARTING THE FIRE Ensure that all the safety precautions mentioned in this manual are being respected. 1. Place 2 logs at the hearth of the firebox. 2. Place a fire starter on top of the logs.

  • Page 9: Disposal Of Ashes

    GLASS DOOR The glass door of your VOLCANO PLUS must be treated with care. Do not slam the door shut or build the fire too close to the glass. Do not overfire. Excessive temperatures or impacts may lead to the breaking of the glass door.

  • Page 10: Glass Cleaning

    Do not over tighten the nuts. Apply high temperature silicone to secure the gasket to the frame. WARNINGS: • Never operate the VOLCANO PLUS without a gasket or with a damaged one. • Do not use substitute materials. GLASS CLEANING The glass door should be cleaned with a soft cloth, using a non-abrasive solution such as soap and water, if necessary.

  • Page 11: Replacement Parts

    Volcano Plus Revised June 2007 REPLACEMENT PARTS ITEM DESCRIPTION SQUARE FAN LR59458 SY FAN SPEED CONTROL KBMC-13BV THERMOSWITCH T-O-D 60T22 DOOR GASKET – FIBER GLASS ROPE 5/8’’ DIA. GLASS GASKET – FIBER GLASS ROPE 5/16’’ DIA. GLASS PYROCERAM 5mm x 13 5/8’’ x 24 1/4’’...
