SUPREME Ambiance Elegance 36 24SF Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Elegance 36
Owner's Manual
Model Number: 24SF
This product is proudly manufactured in North America by SUPREME FIREPLACES INC.
3594 Jarry East, Montreal, QC H1Z 2G4
T: 877-593-4722, F: 514-593-4424
www.supremem.com
Revised: June 2022
IMPORTANT: Keep the owner's manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ambiance Elegance 36 24SF and is the answer not in the manual?

Questions and answers

Related Manuals for SUPREME Ambiance Elegance 36 24SF

Summary of Contents for SUPREME Ambiance Elegance 36 24SF

  • Page 1 Elegance 36 Owner’s Manual Model Number: 24SF This product is proudly manufactured in North America by SUPREME FIREPLACES INC. 3594 Jarry East, Montreal, QC H1Z 2G4 T: 877-593-4722, F: 514-593-4424 www.supremem.com Revised: June 2022 IMPORTANT: Keep the owner’s manual for future use.

  • Page 2: Table Of Contents

    CONTENTS SAFETY ..............................1 GENERAL INFORMATION .......................... 2 Overall Dimensions ..........................2 2.1.1 Traditional Dimensions ......................... 2 2.1.2 Clean Face Dimensions ....................... 3 Specifications ............................4 Combustion Air Control ........................5 Cold Hand Key ............................ 5 Chimney Sweeping Cap ........................5 Door ..............................
  • Page 3 Chase Installation ..........................20 Clearances to Combustibles ......................21 Blower Kit ............................22 OPTIONS ..............................24 Hot Air Kit ............................24 Fresh Air Kit ............................26 OPERATION INSTRUCTIONS ........................27 Fuel ..............................27 First Fires ............................27 Operating the Combustion Air Control ....................27 Starting a High Efficiency Fire ......................

  • Page 4: Safety

    1 SAFETY SUPREME FIREPLACES INC. congratulates you on purchasing an Elegance 36 wood burning fireplace. This manual describes the installation and operation of the Elegance 36 non-catalytic wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s crib wood emission limits for wood heaters sold after May 15, 2015.

  • Page 5: General Information

    2 GENERAL INFORMATION 2.1 Overall Dimensions 2.1.1 Traditional Dimensions Figure 2-1: Elegance 36 Traditional Rectangular Dimensions Figure 2-2: Elegance 36 Traditional Arched Dimensions...

  • Page 6: Clean Face Dimensions

    2.1.2 Clean Face Dimensions Figure 2-3: Elegance 36 Clean Face Rectangular Dimensions Figure 2-4: Elegance 36 Clean Face Arched Dimensions...

  • Page 7: Specifications

    75,000 BTU (21.9 kWh) Efficiency Protocol: CSA B415.1-10 WARRANTY REGISTRATION Please register your SUPREME product online at http://www.supremem.com/warranty.php to ensure full warranty coverage. Proof of purchase is required for all warranty claims. Depending on combustion air control setting (see Section 5.3 for further details).

  • Page 8: Combustion Air Control

    2.3 Combustion Air Control The Combustion Air Control is a patented mechanism (Patent No: US 7,325,541 B2) that regulates the air flow into the firebox based on the temperature of the unit. It is located on the top of the firebox, at the front center of the unit.

  • Page 9: Certification Label

    (Figure 2-10). CAUTION: It is not recommended to remove the baffle. If the baffle needs be removed, please contact SUPREME FIREPLACES INC. beforehand. 2.10 Soapstone Interior The Elegance 36 is lined with 1.25 inch thick soapstone slabs. Soapstone...

  • Page 10: Optional Blower Kit

    (breaker off) before accessing the electrical wiring of the hot air kit. CAUTION: Only a hot air kit provided by SUPREME FIREPLACES INC. can be installed onto the fireplace. Substituting the hot air kit may result in overheating, will void the warranty and can be hazardous.

  • Page 11: Installation Instructions

    Burning Appliances (USA). CAUTION: Modifications/alterations to the unit/installation without written authorization from SUPREME FIREPLACES INC. are strictly forbidden and will void the warranty. Figure 3-1: Straight Wall Installation Refer to Section 1 for further safety information. Carefully read the instructions below before installing your Elegance 36.

  • Page 12: Chimney Installation

    3.2 Chimney Installation The Elegance 36 is approved with a 6” chimney that is listed under the UL 103 / ULC S629 standards (refer to Table 3-1). WARNING: Mixing chimney components from different brands is a safety hazard and will void the warranty on the unit.

  • Page 13: Listed Ul 103 / Ulc S629 Approved Chimney Models (Reference Table)

    3.2.2 Listed UL 103 / ULC S629 Approved Chimney Models (Reference Table) Note that only chimney models listed in Table 3-1 can be installed for the Elegance 36. Table 3-1: List of Approved Chimney Models Manufacturer Models • HS, AC Triple Wall, 6” inner diameter American Metal •...

  • Page 14: Offset Installation

    A 6 inch chimney liner that complies with ULC S635 M2000 (Canada) or UL 1777 (US) standards must be installed within the existing masonry chimney. Note that the 6CON connector (manufactured by SUPREME FIREPLACES INC.) must be installed to connect the prefabricated chimney to the liner (6CON sold separately) unless otherwise specified by the manufacturer of the prefabricated chimney being used.
  • Page 15 • Is in good condition. Note that repairs must be performed on any cracked or missing bricks. • Is thoroughly cleaned of any soot or creosote. • Is not connected to another appliance such as a furnace, hot water heater, or another fireplace. •...

  • Page 16: Surround Installation

    3.3 Surround Installation The Elegance 36 can be installed with either the Traditional surround or the Clean Face surround. 3.3.1 Traditional Surround The traditional surround comprises louvers below (intake) and above (outtake) the door. All components and fasteners are included in the surround kit. Refer to Figures 3-12 and 3-13 and Tables 3-2 and 3-3 for the instructions below.

  • Page 17: Clean Face Surround

    Figure 3-13: Traditional Arched Surround Figure 3-12: Traditional Rectangular Surround Components Components 3.3.2 Clean Face Surround The Clean Face surround comprises no louvers; however, an intake into the chase and an outtake through gravity ducts is required for this configuration. The instructions below describe the installation of the Clean Face surround.
  • Page 18 Figure 3-17: Clean Face Arched Surround Figure 3-16: Clean Face Rectangular Surround Components Components Table 3-4: UWA520 Components Table 3-5: UWA530 Components CLEAN FACE RECTANGULAR CLEAN FACE ARCHED ITEM DESCRIPTION ITEM DESCRIPTION Clean Face front cover Clean Face front cover Clean Face rectangular surround Clean Face arched surround Flange adapter...

  • Page 19: Gravity Kit Installation

    9. Measure the distance between the flange adapter on top of the unit and the flange of the duct/louver adapter and cut the 8” semi-rigid insulated duct (SUPREME part number UCAC8) to the necessary length. Repeat for the other outtake.
  • Page 20 WARNINGS: • The gravity ducts must extend upwards from the top of the unit and cannot exceed 10 feet. • The ducts should never extend downwards; only horizontally or upwards. • The air outtakes must be installed at a minimum of 64 inches from the floor. •...

  • Page 21: Framing

    3.5 Framing The Elegance 36 can be placed directly onto or against normal, combustible construction materials such as lumber, plywood, millboard, particleboard, drywall and decorative wood paneling. The fireplace should NOT be placed directly against or be in contact with an insulation material.

  • Page 22: Calculating R-Value

    Figure 3-25: Hearth Extension Extended to Unit 3.6.1 Calculating R-Value The R-Value is a measurement of a material’s insulating properties with respect to a referenced thickness (see Table 3-7). The total R-Value of the hearth extension constructed out of different materials can be calculated by summing the R-Value of each material with respect to the thickness (see equation below).

  • Page 23: Chase Installation

    3.7 Chase Installation A portion of the front of the chase must be constructed out non-combustible material. Refer to Figure 3-26 for dimensions. Note the chase must be properly fastened onto the framing structure. WARNING: Do not nail or screw the chase onto the fireplace. For the Clean Face surround option, two intake and two outtake openings must be constructed onto the chase.

  • Page 24: Clearances To Combustibles

    3.8 Clearances to Combustibles The clearances below must be respected to ensure safe operation of the unit under normal and extreme conditions. Failure to follow the information below is a safety hazard and may result in property damage. Table 3-8: Overall Clearances Combustible Clearance Reference...

  • Page 25: Blower Kit

    (therm-o-disc) are included with the kit. WARNING: Only blower provided SUPREME FIREPLACES INC. can be installed into the fireplace. Substituting the blower kit may result in overheating, will void the warranty and can be hazardous. The electrical connections are to be performed by a certified electrician.
  • Page 26 Figure 3-30: Electrical Diagram Figure 3-31: Access to Blower Figure 3-32: Blower and its Fixture...

  • Page 27: Options

    CAUTION: Only a hot air kit provided by SUPREME FIREPLACES INC. can be installed onto the fireplace. Substituting the hot air kit may result in overheating, will void the warranty and can be hazardous.
  • Page 28 Installation: 1. Remove the 5’’ knockout on the exterior casing of the fireplace using a flat head screwdriver (Figure 4-2). WARNING: Only remove the knockouts that will be connected to a hot air kit system. 2. Using the knockout as a template, cut the exposed insulation. Make sure to remove any pieces of insulation that has fallen into the unit.

  • Page 29: Fresh Air Kit

    • The air register can be installed above or below the level of the fireplace. • Use the SUPREME FIREPLACES INC. Fresh Air Adapter (ADP4) provided with the unit. • Use the SUPREME FIREPLACES INC. Fresh Air Kit (UPEA4). Figure 4-6: ADP4 Installation in Fireplace Installation: 1.

  • Page 30: Operation Instructions

    5 OPERATION INSTRUCTIONS 5.1 Fuel The Elegance 36 is designed to burn natural wood only. Higher efficiencies and lower emissions generally result when burning air dried seasoned hardwoods (moisture content below 20%), as compared to softwoods or to green or freshly cut hardwoods. The following are a few signs indicating that firewood is sufficiently dry for use: (a) cracks on the ends and surface of the logs, (b) lighter in weight, and (c) color (yellow/grey).

  • Page 31: Starting A High Efficiency Fire

    The left combustion control lever is the Activator. When starting a fire or adding a new load of wood, the Activator must be pushed in to allow maximum air to enter the firebox. The right combustion control lever is the Burn Rate Selector.

  • Page 32: Adding A New Load Of Wood

    used, the door should remain closed at all times. Failing to do so is a safety hazard, will damage the fireplace and void the warranty. WARNING: Do not use fire accelerants to rekindle the fire if the first attempt to start the fire failed. Do not open the door.

  • Page 33: Troubleshooting

    6 TROUBLESHOOTING 6.1 Backdraft / Smoking Draft is the force created by a difference in pressure, which moves air from the appliance up through the chimney. It is important to operate the Elegance 36 with proper draft to ensure optimal performance of the unit. Draft is depended on the length of the chimney, local geography, nearby obstructions and other factors.

  • Page 34: Maintenance

    7 MAINTENANCE 7.1 Disposal of Ashes Ashes should be placed in a metal container with a tight fitting lid. The closed container of ashes should be placed on a non-combustible floor or on the ground, well away from all combustible materials, pending final disposal.

  • Page 35: Cleaning Of Glass

    WARNING: Do not operate the unit with any of the soapstone slabs missing. 7.5 Replacement of Door Gasket SUPREME FIREPLACES INC. assembles heat resistant graphite coated gaskets on the doors of all products, allowing for a proper seal of the unit at extreme temperatures (up to 1000 F).

  • Page 36: Replacement Of Glass

    A slight resistance is expected when closing the door with the new ¾” gasket; the door will close normally after the gasket has taken proper shape. 7.6 Replacement of Glass SUPREME FIREPLACES INC. uses a high quality 5mm Table 7-1: Parts List of Door Assembly thick Pyroceram III / Keralite ceramic glass that can withstand temperatures up to 1300 F.

  • Page 37: Door Latch Maintenance

    7.7 Door Latch Maintenance Lightly lubricate the hook of door latch (SF0031) on a yearly basis to prevent abrasive wear. Occasionally inspect the bushing of the door latch. If required, adjust the tightness of the latch bolt using a 5/32” hex key. 7.8 Paint Paint touch-ups can be performed on the unit using a high temperature paint (in aerosol spray can format) by Stove Bright®...

  • Page 38: Parts List

    8 PARTS LIST Code Description SF0032-01 Black Wood Door Handle PYRO_24.875”X14.75” Pyroceram III / Keralite 5mm Thick Door Glass, 24.875" X 14.75" GSK_31_7 Graphite Coated Round Glass Gasket, 0.3125" thick, 7' length GSK_75_7 Graphite Coated Square Door Gasket, 0.75" thick, 7' length 130CFM_BLW_BRK 130 CFM AC Tangential Blower, 115VAC, 60Hz, 56W, certified VDE, CSA, UL, CE Therm-o-disc, 120VAC, 15A, certified UL/CSA...

  • Page 39: Certification Label

    9 CERTIFICATION LABEL...

  • Page 40: Warranty

    10 WARRANTY SUPREME FIREPLACES INC. warrants that the factory-built fireplaces, fireplace inserts, and stoves will be free from defects in material and workmanship, under normal use and service, for a period of ten (10) years from the date of purchase.
  • Page 41 SUPREME FIREPLACES INC. assume responsibility for them. Freight related damages of products that are shipped directly from the SUPREME INC. warehouse are covered under warranty if they were indicated on the Bill of Lading from the carrier and SUPREME FIREPLACES INC. is notified within 48 hours.
