- Page 1 Flair 34 Owner’s Manual Model Number: 32IN This product is proudly developed and manufactured in North America by SUPREME FIREPLACES INC. 3594 Jarry East, Montreal, QC H1Z 2G4 T: 877-593-4722, F: 514-593-4424 www.supremem.com Revised: June 2022 IMPORTANT: Keep the owner’s manual for future use.
-
Page 2: Table Of Contents
Table of Contents SAFETY ..............................4 COMPONENTS ............................5 Overall Dimensions ..........................5 Specifications ............................6 Combustion Air Control ........................7 Baffle Secondary Burn Technology ..................... 7 Cold Hand Key ............................ 7 Chimney Sweeping Cap ........................8 Door ..............................8 Blowers ............................... - Page 3 First Fires ............................16 Operating the Combustion Air Control ....................16 Starting a Fire ............................ 17 Adding a Load of Wood ........................18 Blower Kit ............................18 Fresh Air Kit (Optional) ........................20 TROUBLESHOOTING ..........................21 Backdraft / Smoking .......................... 21 Over Firing ............................
-
Page 4: Safety
1 SAFETY SUPREME FIREPLACES INC. congratulates you on purchasing a FLAIR wood burning fireplace insert. This insert complies with the ULC S628 and UL 1482 standards. In addition, this wood insert is certified to comply with Phase II particulate emission standards from the US Environmental Protection Agency. -
Page 5: Components
2 COMPONENTS 2.1 Overall Dimensions... -
Page 6: Specifications
2.2 Specifications Adjustable Burn Rate Wood Heater – Non-Catalytic Appliance Type: Fuel Type: Dry Cordwood Maximum Log Length: 22 in (55.9 cm) Burn Time 6 to 12 hrs Firebox Volume: 3.2 ft (0.091 m Heating Area: Up to 2,000 ft (185 m Average Particulate Emissions Rate 1.59 gm/hr... -
Page 7: Combustion Air Control
The baffle system (32SF1150) of the FLAIR insert is located within the upper portion of the firebox and is fastened by 6 bolts (3/8 Hex). SUPREME baffle systems are constructed out a specific grade of stainless steel capable of withstanding high-temperature conditions. -
Page 8: Chimney Sweeping Cap
Contact your local building official regarding mandatory fresh air kit installations within your area. CAUTION: Only a fresh air kit provided by SUPREME FIREPLACES INC. can be installed onto the fireplace. Substituting the fresh air kit may result in overheating and will void the warranty. -
Page 9: Soapstone Interior
2.10 Soapstone Interior The FLAIR stainless steel firebox is lined with a 1.25 inch thick soapstone slabs. Soapstone offers unparalleled advantages in a fireplace beyond its natural aesthetics: it radiates five times more heat and absorbs 15% more heat when compared to firebrick. 2.11 Surround A surround comes standard with the FLAIR (UWB400). -
Page 10: Circulating Chamber
2.13 Circulating Chamber The circulating chamber is a standard component of the FLAIR insert. It is designed to prevent heat escaping to the existing chimney and allows for an optimal flow and heat transfer. The top removable bracket can be taken off during installation to allow for better accessibility to the liner adaptor. -
Page 11: Installation Instructions
CAUTION: Read these instructions carefully before starting the installation. Failure to follow these instructions may result in property damage, bodily harm and even death. Modifications of the instructions presented in this section without written authorization from SUPREME FIREPLACES INC. will void the warranty. -
Page 12: Preparing The Firebox For Installation
3.1 Preparing the Firebox for Installation a) Unfasten and remove the front shipping cover of the unit (Figure 3-3). b) Unfasten the back of the unit from the pallet (Figure 3-4). c) Remove the door by opening it, lifting it, and pulling it towards the bottom until the rod exits from the hinge holes. -
Page 13: Surround Installation
WARNING: The chimney sweeping cap must always block access to the chimney during combustion. A chimney sweeping cap that is not blocking the baffle hole during combustion is a safety hazard, will overheat the fireplace and void the warranty. 3.5 Surround Installation a) Install the surround and secure it with four screws, two on either side. -
Page 14: Clearances To Combustibles
3.6 Clearances to Combustibles Refer to Figure 3-7, Figure 3-6, Table 3-2 and Table 3-3 for clearances to combustibles of the FLAIR insert. Figure 3-8: Clearances to Combustibles (a) Front View (b) Side View Table 3-2: Clearances to Combustibles Note that the non-combustible hearth must 15.5”... -
Page 15: Calculating R-Value
3.6.1 Calculating R-Value The below information demonstrates how to calculate the R-Value for a non-compliant N.F.P.A. 211 hearth extension. The R-Value is a measurement of a material’s insulating properties with respect to a referenced thickness (see Table 3-4). The total R-Value of the hearth extension constructed out of different materials can be calculated by summing the R-Value of each material with respect to the thickness (see equation below). -
Page 16: Operation Instructions
The FLAIR is not intended to serve as a primary source of heat; the home where the FLAIR fireplace insert will be installed must have a primary source of heat. SUPREME is not responsible for heating costs related to other sources of heat. -
Page 17: Starting A Fire
when adding a new charge of wood, the fireplace needs additional air in order to establish a good fire. When the wood starts to burn properly, the amount of air can be reduced depending on the heating requirements. The left combustion control lever is the Activator. When starting a fire or adding a new load of wood, the Activator must be pushed in to allow maximum air to enter the firebox. -
Page 18: Adding A Load Of Wood
the fireplace may not function properly. If the fireplace is deprived of air, it will be necessary to provide a source of fresh air into the dwelling. This may be done by using an air exchanger unit or simply by opening a window or a door near the fireplace partially for a few minutes. - Page 19 Once the power cord has been plugged to the nearest 115V outlet, the fans will turn on and turn off automatically. When the insert gets hot and the thermodisk reaches 95°F, the fans will turn on. The average time it takes for the fans to activate is 30 to 45 minutes after starting a fire as explained in this manual (Section 4.4 Starting a Fire).
-
Page 20: Fresh Air Kit (Optional)
• The air register can be installed above or below the level of the fireplace. • Use the SUPREME FIREPLACES INC. Fresh Air Adapter (ADP4_IN) sold separately. • Use the SUPREME FIREPLACES INC. Fresh Air Kit (PEA4) sold separately. Installation: 1. -
Page 21: Troubleshooting
5 TROUBLESHOOTING 5.1 Backdraft / Smoking Draft is the force created by a difference in pressure, which moves air from the appliance up through the chimney. It is important to operate the FLAIR with proper draft to ensure optimal performance of the unit. Draft is depended on the length of the chimney, local geography, nearby obstructions and other factors. -
Page 22: Maintenance
6 MAINTENANCE 6.1 Disposal of Ashes Ashes should be placed in a metal container with a tight fitting lid. The closed container of ashes should be placed on a non-combustible floor or on the ground, well away from all combustible materials, pending final disposal. -
Page 23: Cleaning Of Glass
WARNING: Do not operate the unit with any of the soapstone panels missing. 6.5 Replacement of Door Gasket SUPREME FIREPLACES INC. assembles heat resistant graphite coated gaskets on the doors of all products, allowing for a proper seal of the unit at extreme temperatures (up to 538 C / 1000 F). -
Page 24: Replacement Of Glass
¾” gasket; the door will close normally after the gasket has taken proper shape. 6.6 Replacement of Glass SUPREME FIREPLACES INC. uses a high quality 5mm thick Pyroceram III / Keralite ceramic glass that can withstand temperatures up to 704 C / 1300 F. -
Page 25: Door Latch Lubrication
6.7 Door Latch Lubrication Lightly lubricate the hook of door latch (SF0031) with graphite grease on a yearly basis to prevent abrasive wear. Occasionally inspect the bushing of the door latch. If required, adjust the tightness of the latch bolt using a 5/32” hex key. -
Page 26: Replacement Parts
6.10 Replacement Parts Refer to the codes from the table below for any replacement parts: Code Description Illustration SF0032-01 Wood pull handle - metallic black Pyroceram III / Keralite 5mm thick glass, PYRO_ 24.25”X17” 24.25" X 17" Graphite coated square gasket, 0.3125" GSK_31_7 (2X) thick, 7' length Graphite coated square gasket, 0.75"... -
Page 27: Warranty
Freight related damages of products that are shipped directly from the SUPREME INC. warehouse are covered under warranty if they were indicated on the Bill of Lading from the carrier and SUPREME FIREPLACES INC. is notified within 48 hours. - Page 28 This warranty is void for any product that has been moved from its original installation location. SUPREME FIREPLACES INC. will not be responsible for environmental conditions and drafting issues such as inadequate vents or ventilation, excessive venting configurations or negative air pressures which may or may not be caused by geographic elements, exterior elements and/or mechanical systems such as exhaust fans, furnaces, clothes dryers, etc.
-
Page 29: Certification Label
7.2 Certification Label...
