Usb Mode Settings; Operating Data Of Microsd Card In The Foma Terminal From A Pc - Docomo Style F-02A Instruction Manual

Updating information causes movie/i-motion containing only sound, if any, saved
in "Movie" folder not to appear in a list. It is recommended that you move the
movie/i-motion with voice only in "Movie" before updating the information, or
change the file name and save the file in PRIVATE DOCOMO MMFILE folder of
microSD card or MUDxxx (xxx is 001-999) in MMFILE using a PC etc.
m [LifeKit] 3eIeSelect a data typeeCe"Yes"
1
✔INFORMATION
Data in "Movie ", "Music", "1Seg" and "i-αppli data" cannot be updated.
If microSD card has much data, updating information takes time.
If available space becomes less than required for creating management information in
FOMA terminal when data is saved in a microSD card with other devices, data saved in
the microSD card may not be displayed correctly on FOMA terminal.
Restoring data in microSD card <Scan card>
The data is not restored by some conditions of microSD card.
m [LifeKit] 3eae"Yes"
1

USB mode settings

Operating data of microSD card in the FOMA
terminal from a PC
To connect FOMA terminal to a PC, FOMA USB Cable with Charge Function 01/02
(optional) or FOMA USB Cable (optional) is required.
Windows 2000, Windows XP and Windows Vista are applicable.
For MTP mode P212 "Saving WMA files"
m [LifeKit] 26
1
2 or 3
2
microSD mode : Set for recognizing microSD card in FOMA terminal as a drive
and operating data.
MTP mode : Set for transferring music data using Windows Media Player to
microSD card.
Setting Communication mode :
Make this setting for packet communication, 64K data communication or data
transfer by connecting a PC.
272
Data Management
1
3
"Yes"
Icons below appear on the stand-by display. Displayed in gray when microSD
card is not installed.
: microSD mode : MTP mode
Connecting to a PC
For connecting method, refer to "Manual for PC Connection" in the attached CD-
ROM. Note that, when using in "microSD mode" or "MTP mode", installation of the
FOMA communication configuration file described in "Manual for PC Connection"
is not required.
When a PC and FOMA terminal are connected,
Press g and select
to display USB mode settings screen. At this time, other
mode than "Communication mode" may not be set if the PC is set to start data
communication automatically when a FOMA terminal is connected.
In microSD mode or MTP mode, the light blinks in blue.
When data is transferred using DOCOMO keitai datalink in Communication mode,
the terminal is in the data transfer mode (the same state as out of service area).
✔INFORMATION
Applying an excessive force to pull the USB cable may give damage to it. And,
removing the USB cable during data transfer may cause malfunction or data loss.
When disconnecting the USB cable from a PC in microSD mode, click
tray in the lower-right corner of a PC screen, click "USB
(E : ) (
*
Storage Device-Drive (E : ) )" and check that message "'USB
(The USB Storage Device can now be safely removed
from the system)" appears.
* The character to be assigned to a drive varies with the system of a PC.
appears on the stand-by display.
in the task
) (Safely Remove (or stop) USB Mass
'
