MICRO COMPONENT SYSTEM

UX-V9MD
REMOTE CONTROL RM-RXUV
9
MD
DIMMER
SLEEP
DISPLAY
FM MODE TAPE / AUX
AUTO
AHB PRO
PRESET
CD
PROGRAM RANDOM
REPEAT
BASS
TREBLE
CANCEL
EDIT
/ TITLE
CHARA
UP
SET
DOWN
MD
TUNER
CD
BAND
VOLUME
INSTRUCTIONS
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bot-
tom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT0247-005A
[A]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UX-V9MD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JVC UX-V9MD

Summary of Contents for JVC UX-V9MD

  • Page 1: Micro Component System

    MICRO COMPONENT SYSTEM UX-V9MD REMOTE CONTROL RM-RXUV DIMMER SLEEP DISPLAY FM MODE TAPE / AUX AUTO AHB PRO PRESET PROGRAM RANDOM REPEAT BASS TREBLE CANCEL EDIT / TITLE CHARA DOWN TUNER BAND VOLUME INSTRUCTIONS For Customer Use: Enter below the Model No. and Serial No.
  • Page 2 CAUTION: Do not open the top cover. There are no user service- able parts inside the Unit; leave all servicing to qualified service personnel. Front view 15 cm MICRO COMPONENT SYSTEM UX-V9MD 1 cm 15 cm STANDBY / ON BAND TUNER...

  • Page 3: Table Of Contents

    The controls and operations have been redesigned to make them very easy to use, freeing you to just enjoy the music. • With JVC’s COMPU PLAY you can turn on the System and automatically start the Radio, CD Player, or MD Player with a single touch.

  • Page 4: Getting Started

    Getting Started Accessories Make sure that you have all of the following items, which are supplied with the System. Power Cord (1) AM Loop Antenna (1) Remote Control (1) Batteries (2) FM Wire Antenna (1) If any of these items are missing, contact your dealer immediately. How To Put Batteries In the Remote Control Match the polarity (+ and –) on the batteries with the + and –...

  • Page 5: Connecting The Fm Antenna

    CAUTION: Make all connections before plugging the System into an AC power outlet. Connecting the FM Antenna Rear Panel of the Unit Connecting the AM (MW/LW) Antenna Rear Panel of the Unit CAUTION: To avoid noise, keep antennas away from the System, the connecting cord and the AC power cord.

  • Page 6: Connecting External Equipment

    CAUTION: Make all connections before plugging the System into an AC power outlet. Connecting the Speakers For each speaker, connect one end of the speaker wire to the speaker terminals on the back of the System. 1. Open each of the terminals and insert the speaker wires firmly, then close the terminals. 2.

  • Page 7: Connecting The Ac Power Cord

    COMPU PLAY JVC’s COMPU PLAY feature lets you control the most frequently used System functions with a single touch. With One Touch Operation you can play a CD, an MD, or turn on the radio with a single press of the play button for that function. One Touch Operation turns the power on for you, then starts the function you have specified.

  • Page 8: Common Operations

    Common Operations REMOTE CONTROL RM-RXUV DIMMER SLEEP DIMMER DISPLAY FM MODE TAPE / AUX DISPLAY AUTO PRESET AHB PRO AHB PRO PROGRAM RANDOM REPEAT BASS TREBLE CANCEL BASS EDIT TREBLE / TITLE CHARA DOWN TUNER BAND VOLUME+,– VOLUME Turning the Power On and Off Turning the System On Press the button.

  • Page 9: Reinforcing The Bass Sound

    Reinforcing the Bass Sound (AHB PRO) You can reinforce the bass sound to maintain rich, full bass at low volume (you can use this effect only for playback): To get the effect, press the AHB (Active Hyper Bass) PRO but- ton.

  • Page 10: Using The Tuner

    Using the Tuner REMOTE CONTROL RM-RXUV DIMMER SLEEP DISPLAY FM MODE TAPE / AUX FM MODE AUTO PRESET AHB PRO AUTO PRESET PROGRAM RANDOM REPEAT BASS TREBLE CANCEL EDIT / TITLE CHARA < > DOWN DOWN TUNER BAND TUNER BAND ¢...

  • Page 11: To Change The Fm Reception Mode

    4. Press the UP, DOWN, >, or < button within 5 seconds to select the preset number. UP or > button: Increases the preset number by 1. DOWN or < button: Decreases the preset number by 1. • When the > or < button is kept pressing, the preset number changes rapidly.

  • Page 12: Using The Cd Player

    Using the CD Player REMOTE CONTROL RM-RXUV DIMMER SLEEP DISPLAY FM MODE TAPE / AUX AUTO AHB PRO PRESET CD 0 PROGRAM RANDOM REPEAT REPEAT PROGRAM RANDOM BASS TREBLE CANCEL CANCEL EDIT / TITLE CHARA < > DOWN DOWN TUNER BAND ¢...

  • Page 13: Programming The Playing Order Of The Tracks

    To stop playing the CD, press the The following information for the CD is displayed. Total track number Total playback time To stop playing and remove the CD, press the CD OPEN/ CLOSE button on the Unit or CD button on the Remote Con- trol to open the CD cover.

  • Page 14: Using The Md Player (Listening To An Md)

    Using the MD Player REMOTE CONTROL RM-RXUV DIMMER SLEEP DISPLAY FM MODE TAPE / AUX DISPLAY AUTO AHB PRO PRESET PROGRAM RANDOM REPEAT PROGRAM REPEAT RANDOM BASS TREBLE CANCEL CANCEL EDIT / TITLE CHARA < > DOWN DOWN TUNER BAND ¢...
  • Page 15 To Select a Track or Passage within a Track —————————————— ¢ During playback, press the (< or >) button to select the track you want. The selected track starts playing. ¢ • Press the button once to skip to the beginning of the next track.

  • Page 16: Recording Onto An Md

    Recording onto an MD REMOTE CONTROL RM-RXUV DIMMER SLEEP DISPLAY FM MODE TAPE / AUX DISPLAY AUTO AHB PRO PRESET PROGRAM RANDOM REPEAT BASS TREBLE CANCEL EDIT / TITLE CHARA DOWN TUNER BAND VOLUME When the System is in use, the display shows oth- er items as well.

  • Page 17: Cd Synchro Recording

    • You can also start recording by pressing the MD REC but- ton and then the MD #¥8 button. When you record a signal from a DAT through the AUX2 ter- minal, two track numbers (track marks) are added for one track. This is not fault.

  • Page 18: Using The Md Player (Editing)

    Using the MD Player (Editing) In addition to its recording and play functions, the MD Player comes with editing functions. You can divide, join, move, or erase the recorded tracks in the MD as required. Also, you can give a disc title to the MD and track titles to the tracks in the MD. Dividing tracks (DIVIDE function) This involves adding a track mark (see Note) at some point during the track which is to be made into the start of an additional track so...

  • Page 19: Dividing Tracks

    Dividing Tracks (DIVIDE Function) Use the Remote Control to carry out this function. 1. Insert an MD to be edited with its label side 2. Press the MD #8 button and then 7 button to set the function to MD. The track numbers and total playback time are displayed.

  • Page 20: Erasing Tracks

    Joining Tracks (JOIN Function) Use the Remote Control to carry out this function. 1. Insert an MD to be edited with its label side up. 2. Press the MD #8 button. • You can also perform this function in Stop mode. 3.

  • Page 21: All Erase Function

    2. Press the MD #8 button. • You can also perform this function in Stop mode. 3. Press the EDIT/TITLE button until “ERASE ?” is displayed. The “EDIT” indicator appears on the display. EDIT DIVIDE JOIN MOVE /TITLE DISC TITLE* TITLE *: Displayed in Stop mode only.
  • Page 22 5. Input a preferred title (up to 64 charac- ters). Use the following buttons to input a title. [Title editing buttons and their functions] (see below) Button Function CHARA Changes the type of characters to be input as fol- lows. Upper-case letters and symbols ≠...

  • Page 23: Using External Equipment

    Using External Equipment AHB PRO PROGRAM RANDOM / TITLE Listening to External Equipment You can listen to external equipment. First make sure that the external equipment is properly connect- ed to the System. (See pages 4-5.) 1. Set the VOLUME control to the minimum position.

  • Page 24: Using The Timers

    Using the Timers REMOTE CONTROL RM-RXUV DIMMER SLEEP SLEEP DISPLAY FM MODE TAPE / AUX SLEEP AUTO AHB PRO PRESET PROGRAM RANDOM REPEAT BASS TREBLE CANCEL EDIT CHARA / TITLE DOWN TUNER BAND VOLUME The timers let you control listening and recording functions auto- matically.

  • Page 25: Setting The Sleep Timer

    5. Setting the volume level. 1. Press the TIMER/SNOOZE button on the Unit. The volume level set by the previous timer setting blinks on the display. ¢ 2. Press the button to select the volume level. : The current volume level will be used. 0 to 50: When the timer is turned on, the Volume will be automatically set to the selected level.

  • Page 26: Information On Mds (Minidiscs)

    Information on MDs (Minidiscs) This is a new digital audio disc format: it has a diameter of 64 mm and enables up to 80 minutes of playback and recording. The cartridge The diameter of the disc itself is 64 mm, smaller than a CD single. The disc sits inside a 68 72 mm cartridge, which also being pocket size, makes minidiscs extremely handy for carrying and storage.

  • Page 27: Md (Minidisc) Messages

    MD (Minidisc) Messages Message BLANK DISC CANNOT JOIN DISC ERROR DISC FULL DISC PROTECTED EMERGENCY STOP MD NO DISC NON AUDIO CANNOT COPY PLAYBACK MD TRACK PROTECTED SCMS CANNOT COPY DIGITAL IN UNLOCK LOAD ERROR Minidisc Limitations The minidisc records information in an original format that differs from that of conventional cassette tapes or DATs. Since there are some lim- itations with this recording format, the following types of conditions may arise.

  • Page 28: Rules Of Digital Dubbing

    Rules of Digital Dubbing The following rules regarding copyright exist for dubbing to MDs from CDs or DATs through digital terminals. SCMS (Serial Copy Management System) Minidiscs can record clear sound with low loss of quality from CDs or DATs through each component’s digital input/output terminal. However, minidiscs are set up so that a disc recorded in this way cannot be recorded onto another minidisc through digital input/output terminals.

  • Page 29: Troubleshooting

    Troubleshooting • If you are having a problem with your System, check this list for a possible solution before calling for service. • If you cannot solve the problem from the hints given here, or the System has been physically damaged, call a qualified person, such as your dealer, for service.

  • Page 30: Specifications

    Specifications Amplifier Output Power 36 W (18 W + 18 W) at 4 ohms (Max.) Input Sensitivity/Impedance (1 kHz) LINE IN (AUX1) 500 mV/65 kohms Optical In (AUX2) –24 dBm - –15 dBm Output Sensitivity/Impedance (1 kHz) LINE OUT 500 mV/4.3 kohms Speaker terminals 4 - 16 ohms CD Player Signal-To-Noise Ratio 90 dB...
  • Page 31 VICTOR COMPANY OF JAPAN, LIMITED 0699MNMCREJSC...
