Specifications
Mains supply 3 x 525-600 V AC Normal overload 110% for 1 minute
Size:
Typical Shaft Output [kW]
IP20/Chassis
IP21/NEMA 1
IP55/Type 12
IP66/NEMA 4X
Output current
Continuous (3 x 525-550 V) [A]
Intermittent (3 x 525-550 V) [A]
Continuous (3 x 525-600 V) [A]
Intermittent (3 x 525-600 V) [A]
Continuous kVA (525V AC) [kVA]
Continuous kVA (575V AC) [kVA]
Max. input current
Continuous (3 x 525-600 V) [A]
Intermittent (3 x 525-600 V) [A]
Additional specifications
Estim. power loss at rated max. load [W]
IP20 max. cable cross-section (mains, motor, brake and
load sharing) [mm
IP55, IP66 max. cable cross-section (mains, motor, brake
and load sharing) [mm
Max. cable cross-section with disconnect
Mains disconnect switch included:
Weight IP20 [kg]
Weight IP21/55 [kg]
4)
Efficiency
10 10
Table 10.7 5)
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.ctiautomation.net - Email: info@ctiautomation.net
72
4)
2
]/[AWG]
2 ]/[AWG]
With brake and load sharing 95 / 4/0
MG11AI02 - VLT
®
VLT HVAC Drive Operating Instructions
P1K1 P1K5 P2K2
1.1 1.5 2.2
A3 A3 A3
A3 A3 A3
A5 A5 A5
A5 A5 A5
2.6 2.9 4.1
2.9 3.2 4.5
2.4 2.7 3.9
2.6 3.0 4.3
2.5 2.8 3.9
2.4 2.7 3.9
2.4 2.7 4.1
2.7 3.0 4.5
50 65 92
6.5 6.5 6.5
13.5 13.5 13.5
0.97 0.97 0.97
®
is a registered Danfoss trademark
P3K0 P3K7 P4K0 P5K5
3 3.7 4 5.5
A3 A2 A3 A3
A3 A2 A3 A3
A5 A5 A5 A5
A5 A5 A5 A5
5.2 - 6.4 9.5
5.7 - 7.0 10.5
4.9 - 6.1 9.0
5.4 - 6.7 9.9
5.0 - 6.1 9.0
4.9 - 6.1 9.0
5.2 - 5.8 8.6
5.7 - 6.4 9.5
122 - 145 195
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
6, 4, 4 (12, 12, 12)
4/12
6.5 - 6.5 6.6
13.5 13.5 13.5 14.2
0.97 - 0.97 0.97
P7K5 P11K
7.5 11
A3 B3
A3 B1
A5 B1
A5 B1
11.5 19
12.7 21
11.0 18
12.1 20
11.0 18.1
11.0 17.9
10.4 17.2
11.5 19
261 300
6.6 12
14.2 23
0.97 0.98
