Specifications
Mains supply 3 x 525-600 V AC Normal overload 110% for 1 minute
Size:
Typical Shaft Output [kW]
IP20/Chassis
IP21/NEMA 1
IP55/Type 12
IP66/NEMA 4X
Output current
Continuous (3 x 525-550 V) [A]
Intermittent (3 x 525-550 V) [A]
Continuous (3 x 525-600 V) [A]
Intermittent (3 x 525-600 V) [A]
Continuous kVA (525V AC) [kVA]
Continuous kVA (575V AC) [kVA]
Max. input current
Continuous (3 x 525-600 V) [A]
Intermittent (3 x 525-600 V) [A]
Additional specifications
Estim. power loss at rated max. load [W]
IP20 max. cable cross-section (mains, motor,
brake and load sharing) [mm
IP55, IP66 max. cable cross-section (mains,
motor, brake and load sharing) [mm
Max. cable cross-section with disconnect
Mains disconnect switch included:
Weight IP20 [kg]
Weight IP21/55 [kg]
4)
Efficiency
Table 10.8 5) With brake and load sharing 95/ 4/0
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.ctiautomation.net - Email: info@ctiautomation.net
®
VLT HVAC Drive Operating Instructions
P15K P18K
15 18.5
B3 B3
B1 B1
B1 B1
B1 B1
23 28
25 31
22 27
24 30
21.9 26.7
21.9 26.9
20.9 25.4
23 28
4) 400 475
2
]/[AWG]
2 ]/[AWG]
12 12
23 23
0.98 0.98
®
MG11AI02 - VLT is a registered Danfoss trademark
P22K P30K P37K P45K
22 30 37 45
B4 B4 B4 C3
B2 B2 C1 C1
B2 B2 C1 C1
B2 B2 C1 C1
36 43 54 65
40 47 59 72
34 41 52 62
37 45 57 68
34.3 41 51.4 61.9
33.9 40.8 51.8 61.7
32.7 39 49 59
36 43 54 65
525 700 750 850
23.5 23.5 23.5 35
27 27 27 45
0.98 0.98 0.98 0.98
P55K P75K P90K
55 75 90
C3 C4 C4
C1 C2 C2
C1 C2 C2
C1 C2 C2
87 105 137
96 116 151
83 100 131
91 110 144
82.9 100 130.5
82.7 99.6 130.5
78.9 95.3 124.3
87 105 137
1100 1400 1500
35 50 50
45 65 65
0.98 0.98 0.98
73
10 10
