Chapter 4 Installing CallPilot Mini/CallPilot 150
25

Figure 3 CallPilot Mini/CallPilot 150 connections

Cable entry slot
Cable trough
Power 9V DC
Port A TCM 1, 3
Port B TCM 2, 4
Ethernet port
Status indicator lights
CallPilot Mini/CallPilot 150 Installation and Maintenance Guide
