S14 Camera Manual
Discreet. Flexible. Hemispheric.
With the S14D FlexMount, two sensor modules featuring microphones are connected to a concealed
camera housing via cables up to 2 m/6.6 ft long. Two adjacent rooms can be discreetly monitored
with just one camera.
HiRes Video Innovations
The German company MOBOTIX AG is known as the leading pioneer in network camera technology and its
decentralized concept has made high-resolution video systems cost efficient.
MOBOTIX AG • D-67722 Langmeil • Tel: +49-6302-9816-103 • Fax: +49-6302-9816-190 • sales@mobotix.com
The HiRes Video Company
EN
HiRes
6 Megapixel
4096 x 1536
Software zoom
Skyline
Format free
Each image format
freely definable
30 Frames/s
VGA (640 x 480)
30 F/s Mega
Virtual PTZ
Digital pan, tilt,
zoom
Backlight
Safe using CMOS
without mechanical iris
Internal DVR
Internal via Flash,
external via Network
Win/Lin/Mac
Recording
via Network on PC
up to 1 Terabyte
Microphone & speaker
Audio
bi-directional via IP,
variable framerates
SIP-Client with video
IP Telephony
Alarm notify,
cam remote control
VideoMotion
Multiple windows
precision pixel-based
-22 to +140 °F
Weatherproof
-30 to +60 °C, IP65,
no heating necessary
IEEE 802.3af
PoE
Network power
even in winter
Robust
No moving parts
fiber glass housing
MxCC/MxEasy
Licence free
Video-Management-
Software

Advertisement

Table of Contents
loading

Related Manuals for Mobotix S14

Summary of Contents for Mobotix S14

  • Page 1 HiRes Video Innovations Robust No moving parts The German company MOBOTIX AG is known as the leading pioneer in network camera technology and its fiber glass housing decentralized concept has made high-resolution video systems cost efficient. MxCC/MxEasy Licence free MOBOTIX AG •...
  • Page 2 ( Support > Manuals ). All rights reserved. MOBOTIX ™, MxControlCenter® and MxEasy® are internationally protected trademarks of MOBOTIX AG. Microsoft , Windows and Windows Server are registered trademarks of Microsoft Corporation. Apple , the Apple logo, Macintosh , OS X , Bonjour , the Bonjour logo and the Bonjour symbol are trademarks of Apple...

  • Page 3: Table Of Contents

    1.10.3 Connection Cable For Sensor Module 1.10.4 MiniUSB Cable to MiniUSB (Straight/Straight Or Straight/Angled) 1.10.5 MiniUSB Cable to USB A Socket 1.10.6 Ethernet Patch Cable For Bayonet Catch 1.10.7 NPA-PoE-Set © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 4 2.5.4 PoE Variables 2.5.5 Power Supply Using A Switch 2.5.6 Power Supply When Connected Directly To A Computer 2.5.7 Power Supply With Power-Over-Ethernet Products 2.5.8 Camera Startup Sequence © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 5 3.6.7 Deactivate Text And Logo Options 3.6.8 Deactivating The Camera Reboot 3.6.9 Browser 3.6.10 Cleaning The Camera And Lens 3.6.11 Safety Warnings 3.6.12 Online Help In The Browser © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 6 All users of MOBOTIX products are therefore required to familiarize themselves with all valid regulations and comply with these laws. MOBOTIX AG is not liable for any illegal use of MOBOTIX products.
  • Page 7 /148 S14D: Dual Camera System With Dual Imaging, Giving Up To 6 Megapixel Resolution S14M: Mono Camera System With Integrated Lens © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 8: Foreword

    Dear MOBOTIX customer, Congratulations on purchasing a highly efficient and discreet premium network camera ”Made in Germany.” MOBOTIX is proud to present the S14 FlexMount , a weatherproof system (IP65), characterized primarily by sensor modules that can be flexibly mounted. In the S14D , two lenses with a sensor board and a microphone are connected to the base module via a 2 m/6.6 ft long cable.
  • Page 9 Please see the Camera Software Manual Part 2 for information on how to operate the camera. This is free to download as a PDF from www.mobotix.com ( Support > Operating Instructions ). The MxEasy and MxControlCenter video software can also be downloaded free-of-charge from Support >...

  • Page 10: The Mobotix Concept

    For example, four lanes of a gas station may be recorded with one single MOBOTIX camera, instead of the four standard cameras normally required for such a task.
  • Page 11 Robust And Low-Maintenance MOBOTIX cameras have no mechanical motors for lenses or for movement. Without any moving parts, these cameras are so robust that maintenance is reduced to a minimum. The unique temperature range from –30°C to +60°C (–22°F to +140°F) is achieved without heating or a fan at only 3 watts.

  • Page 12: Innovative Hemispheric Technology

    Hemispheric cameras are without mechanical moving parts and require low maintenance. In addition, they are silent when panning In-ceiling S14D sensor module and focusing on a specific image area. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 13 Traditional optical PTZ cameras can only record what is being viewed live. The virtual PTZ Integrated MicroSD card feature from MOBOTIX allows users to pan to other areas at a later stage in the recording (max. 64 GB) because the entire room can be recorded as a hemispheric image.
  • Page 14 The S14D boasts double hemispheric features and can replace the time-consuming, expensive installation of several standard cameras while offering surveillance of two adjacent rooms at the same time. This camera, a world first, is evidence of MOBOTIX commitment to innovation as the global leader in megapixel video security systems.
  • Page 15 Virtual PTZ is available for each of the four views. Together with the 180° panorama, the S14 can deliver two more views simultaneously, making it possible to see the overview and to focus on two scenes at the same time (”Panorama Focus” display mode).

  • Page 16: Superior Storage Solution

    Standard system requires an extra PC including software for analysis and storage With the MOBOTIX system, on the other hand, the necessary adjustments to the image format and frame rate for the application concerned (for example, two frames per second are sufficient for recordings in a gas station) are made inside the camera itself, reducing the load on both the network and the recording device (PC, server).
  • Page 17 /148 SD Card Memory Reduces Recording Costs MOBOTIX cameras are also able to record up to 64 GB of video in their integrated memory. Thanks to this high storage capacity and the option of recording only the sequences in which an event occurs, external storage devices such as hard drives are rarely required.

  • Page 18: Added Security Value

    Subsequent Searches Unlike any other surveillance camera, MOBOTIX cameras are capable of recording the full image, even if the user is looking at enlarged detail in the live image. This full image recording can always be reviewed via digital pan/tilt/zoom whenever necessary at a later date.
  • Page 19 The S14 is also equipped with a shock detector as standard. If the camera housing is subjected to an impact, for example, it can simultaneously take video of the offender, trigger an alarm and notify the security company via telephone.

  • Page 20: Cost Benefits And Technical Advantages

    (WLAN). Intelligent Cameras Reduce The Number Of Storage Devices The decentralized MOBOTIX concept enables the user to save around 10 times the standard number of cameras using just one storage device. Event-Controlled Image Format Minimizes Storage Costs Automatic image adjustment (frame rate, size) in the case of movement, noises or sensor action reduces bandwidth and storage requirements.
  • Page 21 Day & Night Maintenance-Free MOBOTIX dual cameras with two sensors and digital switching between day and night modes operate reliably with no mechanical components in all lighting conditions. Simultaneous Recording, Event Search And Live Viewing Live video for multiple users, simultaneous recording and event search possible in seconds from anywhere in the world via a network connection.

  • Page 22: An Overview Of The S14 Flexmount

    S14M: Mono Camera System With Integrated Lens MOBOTIX’s first version of the camera is the S14M model (M = Mono ). Here, a hemispheric lens is directly integrated into the camera housing. The camera features a high-resolution 3 ...
  • Page 23 6 and 30 images per second (6 fps @ 6MEGA, 20 fps @ 3MEGA, 30 fps @ MEGA or lower). © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 24 The entire camera plus cables and lens modules are weatherproof (IP65) and operate in a temperature range of –30°C to +60°C (–22°F to +140°F). Because the S14 is designed to never fog up and does not require any heating, it can be operated all year round with power supplied via a standard PoE network cable.
  • Page 25 Versions and Product Characteristics: Fast, Simple Cabling The MOBOTIX S14 FlexMount (S14D and S14M) requires just one cable for data and power to be connected to a PoE switch and thereby to any expandable Ethernet network. There are two options for a weatherproof connection of the network cable to the S14 housing.

  • Page 26: Hemispheric Image Views

    1.2.1 Overview Featuring hemispheric L11 lenses, the S14 FlexMount offers all the image views known from MOBOTIX’s other hemispheric cameras, including Panorama , Panorama Focus , Double Panorama , Full Image , Normal and Surround . What’s new on the S14D is that the selected view can be displayed as a dual image that combines both sensor modules.
  • Page 27 180° Panorama – Panorama Focus (Wall-Mounted) Panorama Focus – Normal View ”Zoom” (Wall-Mounted) Double Panorama (Ceiling-Mounted) – Panorama Focus (Wall-Mounted) © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 28: Details (Sample Views For One Sensor)

    180° panorama view. Panorama Focus – three views simultaneously High-resolution 180° panorama Original full image Virtual PTZ 1 Virtual PTZ 2 © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 29 This is a superb overview for the user – provided by a single sensor module. Original full image © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 30 The ”Normal” view displays a corrected image section that is easier to pan, tilt or zoom. Original fisheye image: full image Corrected image section: Normal © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 31 North, East, South and West views, or by showing the first 16 saved camera views (one after the other like in a slide show). vPTZ & Zoom © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 32: Main Advantages Of The S14 Flexmount

    LEDs signal a range of operating and alarm states. Up To 64 GB Of Internal Memory The MicroSD card installed in the S14’s camera housing has a capacity of 4 GB (max. 64 GB) and allows for decentralized storage and additional reliability. Adjustable PoE Class Adjusting the PoE class via the camera software also enables the use of PoE switches that cannot be operated on all Class 3 ports (up to max.

  • Page 33: New Features Compared To M12-Devkit

    Enables connection of numerous extensions (MX-GPS-Box, ExtIO, CamIO, etc.) Power supply Via a blue NPA-PoE-Set, MX-NPA-Box or standard PoE switch Directly to S14 via MOBOTIX patch cable or installation cable to the inte- Ethernet connection grated LSA terminal connector Sub-D HD-15...

  • Page 34: General Mobotix Camera Functions

    S14 Camera Manual: An Overview Of The S14 FlexMount General MOBOTIX Camera Functions Like all MOBOTIX cameras, the S14 line has a variety of software functions: from motion detection and long-term storage right through to alarm notification via video IP telephony.
  • Page 35 30 frames per second each, including sound, on a single computer. Internal DVR: Storage On MicroSD Cards MOBOTIX cameras support the direct storage on an internal MicroSD/SD card. By using the integrated DVR, the camera is able to offer the following additional applications: •...
  • Page 36 Remote Alerting In case of an alarm, MOBOTIX cameras can automatically pop up windows or activate other functions at a remote security control center. The cameras can use network/Wi-Fi, GSM/GPRS/UMTS (3G), or Internet connections for this purpose.
  • Page 37 MOBOTIX cameras itive user interface, thus creating a new user experience when viewing and controlling MOBOTIX cameras. The clear design allows up to 16 cameras to be managed, and the application can show up to four cameras at the same time.
  • Page 38 MxEasy is available as a free-of-charge download for Windows and Mac OS X from www.mobotix.com. Diverse Installation Options Not only can MOBOTIX cameras be used under almost all weather and temperature conditions, they also offer suitable installation materials from a wide range of accessories for any conceivable application scenario.
  • Page 39 MOBOTIX provides software updates free-of-charge at regular intervals that improve updates from and expand the camera’s functionalities. Chapter 6, « Software Update» , in the Software www.mobotix.com Manual provides more information on the process. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 40: Lens Options

    S14 Camera Manual: An Overview Of The S14 FlexMount Lens Options MOBOTIX S14 models ship with standard L11 fisheye lens units with a 180° horizontal image angle. The integrated virtual PTZ features of the camera software or MxControlCenter/ MxEasy properly correct the lens distortion that is specific to each of the lenses. These lenses deliver good image quality even when using maximum digital zoom.
  • Page 41 Another benefit is that you can easily set a 35 mm camera (analog or digital) to the same focal length as the MOBOTIX lens (Lxx) to obtain the same field of vision. This approach greatly facilitates lens selection.

  • Page 42: S14 Flexmount Hardware Features

    Microphone integrated into sensor modules – Shock detector Warranty (months) Concealed installation Special Software Features S14 Dual image display – – Dual image storage – – © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 43: Software Features For All Camera Modules

    – Currently available for Q24M-SEC only Model Feature List Image size 3MEGA 3MEGA Image sensor Color Color Color & B/W Color & B/W Audio support (microphone/loudspeaker) © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 44: Technical Data

    VoIP/SIP, two-way communication (with ext. microphone/spea- ker, not included), remote control via key code, event notification Security User/group management, HTTPS/SSL, IP address filter, IEEE 802.1x, intrusion detection, digital image signature © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 45 Approx. 68 g nection cable Standard delivery Housing (high-resistance composite, PBT), white, shock-resistant dome (transparent), mounting parts, Allen wrench, 50 cm/20 in patch cable, manual, software, 4 GB MicroSD card (built-in) © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 46: S14 Flexmount - Scope Of Delivery

    Products > S14 FlexMount and open the basket, that contains the Product  Configurator. Use this to order the required parts in any of the available colors 1.11 1.10 © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 47 Cable plug, 3–5 mm, white (Ethernet installation cable) Allen wrench 2.5 mm Multifunctional tool (lens, dome, filter inserts) Cable tie (Ethernet installation cable, microphone, speaker, MxBus) Screwdriver (screw clamps) © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 48 /148 S14 Camera Manual: An Overview Of The S14 FlexMount Base Module S14D The MOBOTIX S14D consists of a housing, a housing cover and a base plate for attaching the camera. LED defaults: Power (on), Error (flashes) MicroSD card Recording (flashes)
  • Page 49 /148 S14 FlexMount – Scope Of Delivery Internally-Accessible Connections On The S14D The MOBOTIX S14D provides the following internal connections that can be accessed once the cover plugs and housing cover are removed: LSA+ terminal Ethernet installation cable Screw terminals MxBus, microphone,...

  • Page 50: S14D Flexmount - Dimensions

    S14 Camera Manual: An Overview Of The S14 FlexMount 1.9.2 S14D FlexMount – Dimensions 115 mm/4.53 in 100 mm/3.94 in Diam. 5.5 mm/ 0.22 in 13.5 mm/0.53 in Attaching The Base Module Slots M6 tap holes © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 51 /148 S14 FlexMount – Scope Of Delivery 33.5 mm/1.32 in 5 mm/ 0.2 in © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 52: L11 Sensor Module - Scope Of Delivery

    Sensor module with glued-on sealing L11 lens (installed) Dome (installed) Cable retainer with bayonet catch Sealing plug, blue, small (sensor modules, USB, inserted) Nut (reinforced plastic) © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 53: L11 Sensor Module - Dimensions

    = top border of image (North) L11 sensor module housing Pressure compensation element Diam. 43 mm/1.7 in 1.9.4 L11 Sensor Module – Dimensions 58 mm/2.28 in 30.3 mm/1.19 in 15.3 mm/0.6 in Sensor module Weight: 91 g 40 mm/1.6 in Extension © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 54: S14M Flexmount - Scope Of Delivery

    S14 FlexMount and open the basket that contains the Product  Configurator. Use this to order the required parts in any of the available colors 2.10 2.11 2.13 2.12 © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 55 Cable plug, 3–5 mm, white (Ethernet installation cable) Allen wrench 2.5 mm Multifunctional tool (lens, dome, filter inserts) Cable tie (Ethernet installation cable, microphone, speaker, MxBus) Screwdriver (screw clamps) © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 56 /148 S14 Camera Manual: An Overview Of The S14 FlexMount Camera Housing S14M The MOBOTIX S14M consists of a base plate for attaching the camera, a housing with built-in lens, and a housing cover. LED defaults: MicroSD card Power (on), Error (flashes)
  • Page 57 /148 S14 FlexMount – Scope Of Delivery Internally-Accessible Connections On The S14M The MOBOTIX S14M provides the following internal connections that can be accessed once the cover plugs and housing cover are removed: LSA+ terminals Ethernet installation cable Screw terminals MxBus, microphone,...

  • Page 58: S14M Flexmount - Dimensions

    Always print or copy 115 mm/4.53 in drilling templates in 100 mm/3.94 in their original size Diam. 5.5 mm/ 0.22 in 13.5 mm/0.53 in Attaching The Camera Housing Slots M6 tapped slots © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 59 /148 S14 FlexMount – Scope Of Delivery 48 mm/1.89 in 39.5 mm/1.56 in 33.5 mm/1.32 in 5 mm/ 0.2 in © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 60: Available Accessories

    1.10.4 MiniUSB Cable to MiniUSB (Straight/Straight Or Straight/Angled) Order no.: MX-CBL-MU-STR-05/2/5 (straight/straight) Order no.: MX-CBL-MU-EN-STR-05/2/5 (straight/angled) With this cable, which is up to five meters long, MOBOTIX add-on modules (MX-232-IO-Box, ExtIO, CamIO) can be connected directly to the S14. © MOBOTIX AG • Security Vision Systems • Made in Germany...

  • Page 61: Miniusb Cable To Usb A Socket

    1.10.5 MiniUSB Cable to USB A Socket Order no.: MX-CBL-MU-STR-AB-05/2/5 (straight) USB-based storage media (for example, USB hard drives) can be connected directly to the S14 with this cable, which is up to five meters long. 1.10.6 Ethernet Patch Cable For Bayonet Catch Order no.: MX-OPT-CBL-LAN-1/2/5/10...

  • Page 62: Mx-Npa-Box

    MxBus or USB interface. The maximum length of the MxBus cable (diameter: 0.8 mm) is 50 m/55 yd. If the MiniUSB connection is used, the maximum cable length is 5 m/16.4 ft. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 63: Extio Function Expansion

    It is ideal for door communication, elevators, access control, etc. The ExtIO is suitable for use as direct connection to the S14 via a MiniUSB cable (max. 5 m), which can be ordered separately, or as a network con- nection via the PoE switch.

  • Page 64: Installation

    Otherwise this could lead to a build-up of condensation inside the sensor module and its subsequent failure. 2. Unused connectors on the housing of the S14 must always be sealed using the plugs installed as standard on delivery as well as the corresponding retainers.

  • Page 65: Positioning A Hemispheric Camera

    Ceiling-Mounted A single S14 sensor module can monitor an entire room right into each of the four corners (360° Panorama View) thanks to its hemispheric lens. The camera should ideally be positioned on the ceiling in the center of the room. Rooms with a square floor area of up to approx.
  • Page 66 Bearing this in mind, it is advisable to turn the S14 sensor module in rectangular rooms so that the area marked with two arrows or the rotary plug in a S14M (= top border or North of displayed image) is pointing towards one of the longer walls of the room.
  • Page 67 15° wedge for sen- sor module S14M panorama: one camera – three views simultaneously High-resolution 180° panorama Virtual PTZ 1 Virtual PTZ 2 © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 68 (camera focus). The S14 should be installed on a wall such that the two arrows on the back of the sensor module housing (S14D) or the rounded side of the camera housing (S14M) are pointing towards the ceiling.
  • Page 69 (optimal utilization of lens capabilities). MOBOTIX therefore offers easy to install mounting accessories with a 15° tilt for the S14D sensor modules.

  • Page 70: S14D Flexmount Installation Options

    © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 71 If there is a risk of water collecting on the back of the sensor modules (for example, in outdoor areas or in the event of extreme humidity), the modules should not be installed pointing downwards! © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 72 6 megapixels that, in terms of sharpness of detail, significantly outperforms a single hemispheric camera with just one lens. For these kinds of installations, MOBOTIX will soon offer an appro- priate mount in the range of accessories available for the S14 (SurroundMount). The slight downward tilt of the two sensor modules allows the area directly underneath them to be captured with no blind spots.
  • Page 73 15° wedge (accessories) 15 mm/ 0.6 in * Hole diameters vary MOBOTIX also offers the appropriate installation accessories for mounting the sensor depending on mate- rial thickness (see module on thicker walls. Longer ”tunnel holes” through a wall can also be bridged using «Size Of The Drilling...
  • Page 74 (along vehicle longitudinal axis). Sensor modules must be pro- tected against dirt at the top by glass panels or similar! Do not drive over  or step directly on  the camera or sen- sor modules! © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 75: S14M Flexmount Installation Options

    S14M and a microphone capsule behind stainless steel panels or similar materials. go to Products > S14  A similar installation frame is also supplied for the speaker. FlexMount to view and order further accessories for the MOBOTIX S14 system © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 76: Before Mounting

    2.2.1 Overview Of Cable Connections The following cables can be used with the S14 (see also Section 1.10, «Available Accessories» ): • MOBOTIX patch cable : This supplied MOBOTIX cable is designed for direct con- nection to the MX-Patch-Box , the MX-NPA-Box or a standard network port (only in indoor areas).
  • Page 77 /148 Before Mounting Caution Only MOBOTIX cables may be used for the Ethernet and USB connection as well as to the sensor modules (S14D) to ensure the camera remains permanently watertight. Ethernet MiniUSB Sensor cable for LAN Unused connections must be secured using appropriate cable plugs and by...

  • Page 78: Notes On Cable Lengths And Power Supply

    • If you are using IEEE 802.3af or IEEE 802.3at (PoE+) Power-over-Ethernet network components to supply power to MOBOTIX cameras, make sure, if possible, that these components do not have a fan. Since the power consumption of MOBOTIX cameras is very low compared to other products, the reliability of the entire system is increased, thus extending the life of these components.

  • Page 79: Network Connection With Mobotix Patch Cable

    Patch cable Box is available at www.mobotix.com under Products > Accessories > Functional Boxes. Insert the MOBOTIX patch cable of the S14 into the network port for standard connections (only permitted in indoor areas). Connecting Peripheral Devices (MxBus, Microphone, Speaker) The opening provided for the installation cable must be used for all other cables that are connected to the camera when using the MOBOTIX patch cable.

  • Page 80: Network Connection With Installation Cable

    2.2.4 Network Connection With Installation Cable As an alternative to connection to an MX-Patch-Box, MX-NPA- Box or standard network port, you can also connect the S14 directly to an installation cable . Since the housing cover of the camera must be opened for this purpose, this working...

  • Page 81: Using Mxbus Modules

      = 2.2  kOhm, sensitivity –35 ± 4 dB, for example, Panasonic Microphone Capsule WM61 • Speaker : Max. power output 400 mW at 8 Ohms impedance, for example, Visaton Speaker K36WP or K50WP © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 82: Replacing The Microsd Card

    • Drilling template for base plate and, where appropriate,. sensor module(at the end of this manual) • Scissors to cut out the template © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 83: Preparatory Steps

    • Even surface : Make sure before attaching the camera that the surface is even so that the base plate of the camera does not move. • Pressure equalization element : This element on the housing of the S14 and the sensor modules must be kept free to enable pressure equalization element of the camera housing.

  • Page 84: Installing The S14D Flexmount

    3. Screw on the S14D base module using the 4×40 mm screws included (or other suitable screws) and washers (with a diam. of 4.3 mm). © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 85: Attaching And Connecting The S14D Sensor Modules

    6. Now insert the cable and then push the whole sensor module (including wedge, lettering is pointing wedge sealing and extension, if installed) through the hole. upwards! © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 86: Plugging In And Lifting Off Extensions

    (see blue box in the illustration on the right). Push the extension with the notches onto the sensor module. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 87: Connecting Network Cables And Additional S14D Cables

    MiniUSB cable, if required, and additional cables (MxBus, microphone, speaker) as described in Section 2.5, «Network And Power Connection, Additional Cables» . © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 88: Installing The S14M Flexmount

    Make sure the camera is mounted on an is a risk that the housing plate will move and the housing will begin to leak. for the housing cover screws is 0.4 Nm. torque © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 89 (acces- the camera on tightly (secure nuts with a screw locking device to prevent them from sories) for this type becoming loose). of attachment © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 90: Network And Power Connection, Additional Cables

    Box is available at www.mobotix.com under Products > Accessories > Functional Boxes. Insert the MOBOTIX patch cable of the S14 into the network port for standard connections (only permitted in indoor areas). If additional cables are required inside the housing (MxBus, microphone, speaker), they must be connected as described in Section 2.5.3, «Connecting Additional Cables»...

  • Page 91: Network Cabling For S14 With Patch Cables

    The rubber sleeve must sit tightly on the installation cable to prevent the penetration of moisture. Tighten the cable tie around the shield mesh to ensure less tension. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 92 Hint : Hold the cable ends firm before cutting them with the LSA+ tool. If additional cables are required inside the housing (MxBus, microphone, speaker), they must be connected as described in Section 2.5.3, «Connecting Additional Cables» . © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 93: Connecting Additional Cables

    4. Fix single wires or cables to the base plate using one of the cable ties supplied. 5. Connect wires to the corresponding devices (MxBus module, microphone, speaker). © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 94: Poe Variables

    Full power mode; max. 4 W for peripheral devices 6.49 W–12.95 W (e.g. MX-GPS-Box on MxBus) The MOBOTIX factory default is PoE class 2. This default setting is usually fine, and noth- PoE Variables: Multiple cameras ing needs to be changed. However, the PoE power class must be changed in the browser...

  • Page 95: Power Supply Using A Switch

    NPA-Set, Power-Box and Camera Power-Rack (MX-NPA- RJ45 Set, MX-NPR-4 and MX-NPR8/20) are not suitable for use with the S14 LAN/www Camera (10.8.0.99) (10.8.0.11/255.0.0.0) © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 96: Power Supply When Connected Directly To A Computer

    PoE switch/router. The switch/router must support the PoE standards IEEE 802.3af or IEEE 802.3at. The IP addresses in PoE/PoE+ the diagram are shown LAN/www switch/router only as an example (10.8.0.11/255.0.0.0) Camera (10.8.0.99) © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 97: Camera Startup Sequence

    MxControlCenter, MxEasy, etc.). Note During the startup sequence of the camera, the LEDs will always light up, even if they have been deactivated in Admin Menu > LED Setup. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 98: Operating The Camera

    (for example, 10.8.0.99). However, local computer networks usually have IP addresses in the 172 or 192 ranges. In order to access a MOBOTIX camera via the network, the camera needs to obtain an IP address in the same address range. You can set up the network parameters of the MOBOTIX camera using one of the following methods: Manually, using MxCC and MxEasy or by DHCP.

  • Page 99: Manually Using A Computer In The 10.X.x.x Ip Address Range

    – The setup does not work automatically. – You need to know the relevant network parameters. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 100: Automatically Using Mxcontrolcenter Or Mxeasy

    MxControlCenter or MxEasy (see Section 3.2.3 and Section 3.2.4 ). You can also use one of these applications to automatically configure the network parameters of MOBOTIX cameras that are not operating on the same IP address range as the computer. MxControlCenter software (free download from www.mobotix.com)

  • Page 101: Automatically Using Dhcp

    – The camera needs to be physically accessible as you need to press a key on the camera housing to boot it using DHCP. – Requires a running DHCP server on the network. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 102: First Images And The Most Important Settings

    S14 Camera Manual: Operating The Camera First Images And The Most Important Settings Once the MOBOTIX camera has been connected to the network, you need to set up the camera’s network interface accordingly. This step involves setting up and checking the network parameters of the camera.
  • Page 103 2. Set Up The Target Network Parameters Of The MOBOTIX Camera: 1. Open a web browser on the computer and enter the default IP address of the MOBOTIX camera in the address bar of the browser (for example, 10.8.0.99). Pressing Enter displays the user interface of the MOBOTIX camera (see also Section 3.2.2, «First...

  • Page 104: First Images And The Most Important Settings In The Browser

    3.2.2 First Images And The Most Important Settings In The Browser Once the MOBOTIX camera has been connected to the power supply and to the network, you can access the user interface with the live camera image in the web browser. Internet Explorer, Firefox, Safari or any other graphical browser with activated JavaScript is suitable.
  • Page 105 For more information on camera screens, see the section ”Camera Screens In The Guest screen: Browser” in the Camera Software Manual Part 2 or the online help of the camera’s http://<camera IP>/ cgi-bin/guestimage.html user interface. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 106: First Images And Network Parameter Configuration In Mxcontrolcenter

    Installation Download the setup file from the MOBOTIX website to install the latest version. The latest versions are available at www.mobotix.com in the Support > Software Downloads > MxControlCenter section. To install MxControlCenter, simply double-click on the setup file and follow the instructions.
  • Page 107 The Add Video Sources dialog box appears and the application automatically searches for MOBOTIX cameras in the local network when you launch the program for the first time. Select Video Source > Add from the menu to perform a camera search at a later time.
  • Page 108 For more information, see «Creating A New Layout» further down. Reconfiguring Cameras In A Different Subnet If one or more MOBOTIX cameras are displayed with the status Different subnet (for example, cameras with a factory IP address), MxControlCenter automatically offers to configure the network settings of these cameras.
  • Page 109 MxControlCenter. • Camera: Here, you can enter the known IP address or DNS name of a MOBOTIX camera or a third-party IP camera if it was not found by the automatic search feature.
  • Page 110 If you select the second option, the video sources you selected are simply integrated in the MxCC system where you can use them to generate a layout at a later time. Click on OK to confirm. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 111: First Images And Network Parameter Configuration In Mxeasy

    When you start MxEasy for the first time on a computer, the MxEasy Assistant automatically begins to search for MOBOTIX cameras and displays all cameras found in a list. The camera list will be updated automatically as soon as new MOBOTIX cameras are connected to, or removed from the network.

  • Page 112: Integrating And Displaying Cameras

    S14 Camera Manual: Operating The Camera Reconfiguring Network Addresses Of Cameras Using Bonjour*, MxEasy finds not only cameras on the same network as your computer, but also MOBOTIX cameras located in other subnets (the Invalid Network status). In such a *Bonjour: automatic recognition of network...
  • Page 113 For more information, see the MxEasy User Manual, which can be downloaded as a PDF file from the MOBOTIX website: www.mobotix.com > Support > Manuals. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 114: Starting The Camera With The Factory Ip Address

    As opposed to resetting the camera using Admin Menu > Reset configuration to factory defaults, the user information will not be reset if the camera is booted using the factory IP address. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 115: Starting The Camera With An Automatic Ip Address (Dhcp)

    3.2.7 Starting The Camera With An Automatic IP Address (DHCP) If your network has a DHCP server, you can start the MOBOTIX camera with DHCP support. The camera automatically obtains an IP address from the DHCP server and announces the new network data.

  • Page 116: Virtual Ptz And Full Image Recording

    Operation Using The Mouse And Scroll Wheel The vPTZ function of the S14 can be controlled in the browser using the mouse. This posi- tion becomes the new image center by clicking on any position on the image displayed on the monitor.
  • Page 117 PTZ Features» , the MxControlCenter manual, Section 2.4.6, «Using the vPTZ Features» and Section 3.1.4, «The “PTZ Controls” Section In The Sidebar Panel» ). Current versions of all manuals can be downloaded anytime from the MOBOTIX website www.mobotix.com under Support > Manuals).

  • Page 118: Full Image Recording

    Full image recording off: The event that triggered a video motion (VideoMotion VM) window may not be in the recorded sequences while the window was not displayed at the time. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 119 Activate/Deactivate Full Image Recording In The Browser To configure this feature, open the Setup Menu > Event Control > Recording dialog box and activate or deactivate the Full Image Recording option. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 120: Special S14 Configuration In The Browser

    S14 Camera Manual: Operating The Camera 3.3.3 Special S14 Configuration In The Browser The MOBOTIX S14M and S14D with one or two D11/N11 sensor modules offer a range of special configuration options for the image settings due to their hemispheric lenses.
  • Page 121 Panorama and Surround respectively. Every other display mode can be operated in the same way. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 122 These tilted lines are primarily caused if the camera or sensor module is tilted (for example, due to mounting with 15° wedges) or if the image tilt is modified. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 123 6. Click on the lock icon again to close it (lock clasp is down). The panorama image setting is then locked until the camera is next restarted. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 124 Bring columns together at the (neces- sary to correct the example on the left) Bring columns together at the bottom © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 125 2. Rotate the live image in the desired direction using the mouse or a joystick con- For vPTZ use and nected to the computer. the configuration of a USB joystick, see Section 3.3.1 vPTZ © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 126 In the next step, you can set these views as the standard view for the camera live image. North East West South Caution: No OnScreen Control is available in ”Double Panorama” mode © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 127 When you click inside one of the subviews, this area is highlighted with a yellow frame. All of the PTZ actions triggered by the mouse, joystick or OnScreen Control now only apply to the highlighted subview. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 128 • Adding/switching on sensor modules: This is where you can re-enable deactivated modules. • Removing/switching off sensor modules : This is where you can deactivate any connected modules if needed. Cam1 Cam2 © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 129 Virtual PTZ And Full Image Recording Configuration Of Audio Settings Thanks to the MOBOTIX S14 system’s flexible layout, there are a number of different micro- phone options depending on the model used (S14D, S14M): Information on how to connect external microphones and speakers is provided in Section 2.2.8, «External Audio Support (Microphone/Speaker)»...

  • Page 130: Microsd Card Recording

    Admin Menu > Camera Status dialog box. Conservative Memory Usage Thanks To MOBOTIX MxFFS File System MxFFS formatting of the MicroSD card means that MOBOTIX camera software will use the flash device as evenly as possible, thus allowing for the maximum possible number of write/delete cycles.
  • Page 131 (Admin Menu > Storage on External File Server / Flash Device). This leaves enough time to exchange the MicroSD card before the danger of data loss becomes too high. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 132: Formatting The Microsd Card

    MxFFS-formatted). The following steps are necessary to format a storage device Flash Device (Admin Menu > Storage on External File Server / Flash Device): 1. Make sure that there is a MicroSD card in the card slot of the MOBOTIX camera. 2. Click on Format in the SD Flash Card line.

  • Page 133: Activate Recording

    MxFFS-formatted (Admin Menu > Storage on External File Server / Flash Device): Storage on External File  Server / Flash Device 1. Make sure that there is a MicroSD card in the card slot of the MOBOTIX camera. 2. Make sure that the MicroSD card is formatted in MxFFS format. 3. Activate the SD Flash Card option.

  • Page 134: Accessing Camera Data

    • In MxControlCenter: Play back the recorded video sequences with audio by accessing the MicroSD card in the MOBOTIX camera via the camera or with a direct access to the MicroSD card via a card reader connected to the computer. Access the card by setting the MicroSD card’s drive/volume as a directory in MxControlCenter.

  • Page 135: Using A Microsd Card In A Different Mobotix Camera

    This is limited to 4 MB of lost data per incident due to MxFFS formatting. 3.4.6 Using A MicroSD Card In A Different MOBOTIX Camera A MicroSD card containing recorded video data from a MOBOTIX camera can be inserted into any MicroSD card-enabled MOBOTIX camera. Once a MicroSD card recording has been activated (requires a reboot), the ”new”...

  • Page 136: Configuration In The Browser

    HTTP commands using programs and scripts of the embedded software. The settings are stored in the camera’s flash memory. This section contains an overview of the general browser settings of the MOBOTIX camera, as well as further configuration options. The Software Camera Manual Part 2 contains more detailed descriptions of the software features.
  • Page 137 (Image Programs Quick Control). => ( Software Camera Manual Part 2 , Section 5.5.2 ) • Set the resolution of the live image: By factory default, all MOBOTIX cameras are delivered with an image resolution of 640 x 480 pixels. You can select the desired resolution using the Resolution Quick Control.
  • Page 138 For more information, see the online help for the camera (see Section 3.6.12, «Online Help In The Browser» ). • Activate shock detector: The S14 is the first MOBOTIX camera with a pre-installed shock detector (for all IT and Secure versions). If, for example, the camera’s housing receives a blow, it automatically registers it and send a notification via a network message or telephone call.

  • Page 139: Additional Configuration Options

    This allows you to manually synchronize the camera with a computer or automatically using a time server or another MOBOTIX camera. The camera can use either NTP time servers or Time Protocol servers. For additional information, see Section 5.4.2, «Date And Time/ Time Zones And Time Servers»...

  • Page 140: Additional Notes

    If the camera’s IP address is not known, you can start the camera with its factory IP address. Section 3.2.6, «Starting The Camera With The Factory IP Address» describes this procedure in more detail. © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

  • Page 141: Resetting The Camera To Factory Settings

    As camera arming is deactivated in its default configuration (see preceding section), the MOBOTIX camera displays only the text WWW.MOBOTIX.COM, the time stamp and the You can deactivate and MOBOTIX logo at the top of the image. Once the camera arming has been activated, the customize the text and logo display settings text at the bottom of the live image (event, action, messaging and recording symbols) will also appear.

  • Page 142: Browser

    § regulations for video and sound monitoring when using MOBOTIX products. Depending on national laws and the installation location of the S14, the recording of video and sound data may be subject to special documentation or it may be prohibited.

  • Page 143: Online Help In The Browser

    Electrical and electronic products contain many reusable materials. For this reason, we would ask that you dispose of MOBOTIX products at the end of their service life in accor- dance with all legal requirements and regulations (or deposit these products at a munic- ipal collection center).
  • Page 144 S14 Camera Manual: Operating The Camera 3.6.15 Disclaimer MOBOTIX AG does not assume any liability for damage that is the result of improper use of its products or failure to comply with the operating manuals or the applicable rules and regu- lations.
  • Page 145 /148 Notes © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 146 /148 S14 Camera Manual: Declaration of Conformity S14 FlexMount Camera Original declaration of conformity: www.mobotix.com > Support > Media Library > Certificates © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 147 VAT ID: sales@mobotix.com DE202203501 You can fi nd the latest version of this document at www.mobotix.com under Support. Technical specifi cations subject to change without notice! © MOBOTIX AG • Security Vision Systems • Made in Germany www.mobotix.com • sales@mobotix.com...
  • Page 148 HiRes Video Innovations Robust No moving parts The German company MOBOTIX AG is known as the leading pioneer in network camera technology and its fiber glass housing decentralized concept has made high-resolution video systems cost efficient. MxCC/MxEasy Licence free MOBOTIX AG •...
  • Page 149 The HiRes Video Company Scale 1:1 115 mm/4.53 in 100 mm/3.94 in Diam. 33.6 mm/ 1.32 in 100 mm/3.94 in Slot holes 10.5 mm/0.41 in, diam. 5.5 mm/0.22 in Tap holes M6 Drill hole for lens diam. 33.6 mm/1.32 in (S14M only) © MOBOTIX AG • Security-Vision-Systems • Made in Germany www.mobotix.com • sales@mobotix.com...

Table of Contents
