A.4. Batch Solo Setup Function
The Batch Solo Setup function enables you to install and setup multiple cameras without requiring another
person's assistance.
To perform a batch Solo Setup
Select the Setup > Analytics > Advanced screen, which displays all analytic units in the physical
site (VLAN). The Advanced screen is displayed. The web page searches for the ioimage units
and adds them to the Available Units list. Units using firmware version 1.5.7.328 will also be
discovered.
From the Available Units list, select the checkbox for the units to setup or click Select All.
Click the Record icon
In the dialog box, enter the name of the directory in which you want to save the data. By
default, the data for each camera is stored in a folder whose name is the camera's IP address.
Click the Stop icon
24
to start recording. The Browse for Folder dialog box opens.
when finished recording.
