- Page 1 DVTEL INC. 65 Challenger Road Ridgefield Park, NJ 07660 trk1 Installation Manual The contents of this guide may not be reproduced or reprinted in whole or in part without the express written permission of DVTEL, INC. Ver. A1 April 2013...
-
Page 3: Table Of Contents
Reset by Removing the Power Supply ..............13 Solo Setup ........................13 Appendix ..........................15 A.1. Technical Specifications ....................16 A.2. Connecting Leads to a Spring Clamp Terminal Block ........... 18 A.3. Solo Setup Window ...................... 19 A.4. Troubleshooting ......................21 Contacting DVTEL .........................24... - Page 4 trk1 Installation Manual List of Figures Figure 1: trk1 Unit ............................1 Figure 2: trk1 Unit Connectivity ......................... 1 Figure 3: trk1 Power Connection Panel ..................... 2 Figure 4: trk1 Video Connection Panel ...................... 3 Figure 5: trk1 with Nuts Removed ......................6 Figure 6: Inserting Units into Rack Mount Panel ..................
-
Page 5: Document Information
This manual and its contents herein are owned by DVTEL, Inc. All rights reserved. DVTEL, the DVTEL logo, ioimage, the ioimage logo, ioimage analytics®, ioiware, ioibox, trk1, trk10d, trk100, trk100d, trk-101, trk200, trk4000d, trk8000, ioiware command center, ioiware setup, ioicam mmp100dn, IOI-XTRK-10D, IOI-XTRK-100D, XPVA-10D, XPVA-100D, and sc1dn-A are trademarks of DVTEL, Inc. -
Page 6: Document Conventions
DVTEL, Inc. and its agents make no guarantees or warranties to the suitability for the users’ intended use. DVTEL, Inc. accepts no responsibility for improper use or incomplete security and safety measures. - Page 7 Document Information Warning: 1. Only qualified trained personnel should service and repair this equipment. 2. Observe local codes and laws and ensure that installation and operation are in accordance with fire, security and safety standards. Electrical Safety Notice and Warnings Warning: 1.
-
Page 8: Site Preparation
trk1 Installation Manual Caution: To avoid damage from overheating or unit failure, assure that there is sufficient temperature regulation to support the unit’s requirements. Operating temperature should be kept in the range 0° to 50°C (32° to 122°F), with no more than 95% non-condensing humidity. Minimizing EMI and RFI When wires run for a significant distance in an electromagnetic field, electromagnetic interference (EMI) can occur. -
Page 9: Introduction
Introduction 2 Introduction The trk1 is a self-contained video analytic IP encoder that monitors the video input from a camera, providing real-time detection and autonomous tracking capabilities. Operators can define rules, perimeter lines, sterile zones and other criteria for intrusion detection. In addition to its analytic capabilities, the encoder also transforms the input video into a standards-compliant, compressed IP video stream. -
Page 10: Items Included In The Package
trk1 Installation Manual 2.1 Items Included in the Package The unit package contains the following items: Description trk1 encoder AC adaptor with power cord Terminal block spring clamp connectors Documentation and utilities CD Related Documentation: HTML Edition Units User’s Guide ... -
Page 11: Video Connection Panel
Introduction Item Description Ethernet For connecting the unit to the Ethernet network (10/100 Mbps) and powering 802.3af PoE the unit via PoE. Network Port (RJ-45) External Terminal block for the following connections: Devices DRY IN (Alarm Input): Single alarm input connection (a set of two wires) from Connection an external device —... - Page 12 trk1 Installation Manual The video connection panel of the unit includes the following items: Item Description Video In Input interface for receiving the surveillance camera analog video signal (source) for (BNC) analysis and detection. Video Out Output interface that provides the PAL or NTSC analog video signal after analysis (BNC) and includes detection overlays and additional On-Screen Display (OSD) information.
-
Page 13: Installing And Connecting The Unit
Installing and Connecting the Unit 3 Installing and Connecting the Unit This section describes how to install and connect the unit and includes the following sections: Installing the Unit (page 5) Connecting the Unit (page 8) Resetting the Unit (page 13) Note: After connecting the unit, proceed to configure the unit as described in the HTML Edition... -
Page 14: Assembling The Unit In A Rack Mount Panel (Optional Accessory)
trk1 Installation Manual 3.1.1 Assembling the Unit in a Rack Mount Panel (Optional Accessory) Up to 8 units can be mounted on a single rack mount panel. After the units have been assembled in the rack mount panel, the panel can be installed in a standard 19-inch rack. To assemble units in a rack mount panel Remove the nut and washer from each of the two video connectors on the video connection panel of the unit. -
Page 15: Figure 7: Unit Secured To Rack Mount Panel
Installing and Connecting the Unit Fasten each unit using the nuts and washers removed in step , making sure to first place the washer on each video connector before tightening the nut on the video connector. Figure 7: Unit Secured to Rack Mount Panel ... -
Page 16: Connecting The Unit
trk1 Installation Manual 3.2 Connecting the Unit This section describes the procedures for connecting the unit and includes the following sub-sections: Grounding the Unit (page 8) Connecting the Unit to the Power Supply (page 8) Connecting the Unit to the Network (page 9) ... -
Page 17: Connecting The Unit To The Network
Installing and Connecting the Unit Note: It is also possible to utilize Power over Ethernet to power the unit via the network cable connection to the Ethernet 802.3af PoE port. 3.2.3 Connecting the Unit to the Network By default the unit is shipped with the factory default IP address 192.168.123.10. Caution: Before connecting the unit to the network, set the unit IP address according to your specific network requirements to avoid address conflicts. -
Page 18: Connecting The Video Source (Camera) To The Unit
trk1 Installation Manual Figure 9: Configurator Window In the Unit network configuration section, enter the IP address, Subnet mask, and Gateway IP address. Note: It is possible to set the IP address without changing the subnet. If you will use a DHCP server, select the DHCP checkbox. You may change the IP address for a single unit or multiple units. -
Page 19: Connecting The Unit To Receive Alarms From External Devices (Alarm Inputs)
Installing and Connecting the Unit The analog video output (composite video) contains the video from the camera combined with On-Screen Display (OSD) overlays such as detected objects, tracking boxes and trails, time stamp, alarm, camera status, and so on. These OSDs can be enabled and customized using the unit’s embedded web interface. The analog video output can be monitored using an analog monitor or recorded on a digital video recorder (DVR). -
Page 20: Figure 10: Relay Contacts
trk1 Installation Manual Relay Output Specifications Maximum current 1A @ 24VDC Relay Contacts Schematic Figure 10: Relay Contacts NC: Terminal for connecting one of a pair of wires that leads to an external device on a circuit configured for NORMALLY CLOSED ... -
Page 21: Resetting The Unit
Installing and Connecting the Unit 3.3 Resetting the Unit The unit can be reset as follows: Reset Using the Reset Button (page 13) Reset by Removing the Power Supply (page 13) 3.3.1 Reset Using the Reset Button The unit has a reset button located on the power connection panel of the unit. See Figure 3: trk1 Power Connection Panel. -
Page 23: Appendix
Appendix Appendix This section contains the following appendices: Technical Specifications (page 16) Connecting Leads to a Spring Clamp Terminal Block (page 18) Solo Setup (page 19) Troubleshooting (page 21) -
Page 24: Technical Specifications
trk1 Installation Manual A.1. Technical Specifications Following are the trk1 technical specifications: Video Input channels Number of Intelligent Video Analysis Channels Analog Video Inputs Video Signal Composite 1Vp-p (PAL or NTSC) Physical Connector 1 x BNC 75Ω Analog Video Outputs Video Signal Composite 1Vp-p (PAL or NTSC) Physical Connector... - Page 25 Appendix Physical Dimensions Dimensions (mm) 88 x 26 x 130 mm (W x H x D) Dimensions (inches) 3-7/16” x 1” x 5-3/32” (W x H x D) Mounting Camera Housing/Shelf/Optional rack-mounting (multiple-unit accessory) Environmental Specifications Operating Temperature 0° to 50°C (32° to 122°F) Operating Humidity 5% to 95% (non-condensing) Certifications...
-
Page 26: Connecting Leads To A Spring Clamp Terminal Block
trk1 Installation Manual A.2. Connecting Leads to a Spring Clamp Terminal Block The unit is delivered with two terminal block connectors. The connectors enable you to connect wires for either the relay output or alarm inputs and then connect them to the unit. Figure 11: Spring Clamp Terminal Block To connect a wire to the spring clamp terminal block: Strip the insulation from the end of each wire that is to be connected to the terminal block. -
Page 27: Solo Setup Window
Appendix A.3. Solo Setup Window The Solo Setup function enables you to install and setup a camera without requiring another person’s assistance. To perform a Solo Setup Open the Setup > Analytics > Depth window. The following screen is displayed: Figure 13: Solo Setup Window Open the Solo Setup tab. - Page 28 trk1 Installation Manual On the Solo Setup control keypad, click Start Recording to record a view in the camera’s field of view. Select a folder where to store the clip. Recording starts when the folder is selected. Walk through various locations across the vertical axis of the camera’s field of view in order to place ground and height markers and guidelines in the clip.
-
Page 29: Troubleshooting
Appendix A.4. Troubleshooting This section provides useful information and remedies for common situations where problems may be encountered. Problem Possible Solution No network connection Hardware issues: Check that the network is working and the unit is powered on. Check that the network (Ethernet) cable is properly attached to the unit. - Page 30 trk1 Installation Manual Problem Possible Solution Bad output video quality Check the source video signal quality by connecting an analog monitor to the video source. If video quality is acceptable, connect video source to the unit. Check that the cables are connected securely. This includes junction boxes and amplifier that may be used.
- Page 31 Appendix Problem Possible Solution Relay outputs are not Check the unit settings to confirm that the relay output is enabled. working Refer to the HTML Edition Units User’s Guide for details. Check that a proper rule for activating a relay output has been defined in the unit or activate it manually.
-
Page 32: Contacting Dvtel
Tel: +86-10-8586-8836 Mobile: +86-13501266857 Fax: +86-10-85868815 To request the latest versions of firmware and software or to download other product-related documents, visit http://www.dvtel.com/support. If you have obtained a login go to our support gateway. For assistance, email us at support@dvtel.com...
