Teridian 73S1210F User Manual

Multi-sam evaluation board lite
Hide thumbs Also See for 73S1210F:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
TM
Simplifying System Integration
73S1210F
Multi-SAM Evaluation Board Lite
User Guide
August 20, 2009
Rev. 1.0
UG_1210F_036

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 73S1210F and is the answer not in the manual?

Questions and answers

Related Manuals for Teridian 73S1210F

Summary of Contents for Teridian 73S1210F

  • Page 1 Simplifying System Integration 73S1210F Multi-SAM Evaluation Board Lite User Guide August 20, 2009 Rev. 1.0 UG_1210F_036...
  • Page 2 Fedora is a registered trademark of RedHat, Inc. All other trademarks are the property of their respective owners. Teridian Semiconductor Corporation makes no warranty for the use of its products, other than expressly contained in the Company’s warranty detailed in the Teridian Semiconductor Corporation standard Terms and Conditions.

  • Page 3: Table Of Contents

    Figure 4: Emulator Window Showing Erased Flash Memory and File Load Menu ........8 Figure 5: 73S1210F Multi-SAM Evaluation Board Lite Jumper, Switch and Test Point Locations .... 14 Figure 6: 73S1210F Multi-SAM Evaluation Board Lite Electrical Schematic ..........15 Figure 7: 73S1210F Multi-SAM Evaluation Board Lite Top View (Silkscreen) .........

  • Page 4: Introduction

    Section 4.6. The 73S1210F Multi-SAM Evaluation Board Lite can be programmed to run any of the Teridian turnkey applications or a user-developed custom application. Teridian provides its Pseudo-CCID application preloaded on the board and an EVM testing application on the CD.

  • Page 5: Evaluation Kit Contents

    • Power interface • ON/OFF switch • 1 LED Recommended Equipment and Test Tools The following equipment and tools (not provided) are recommended for use with the 73S1210F Multi-SAM Evaluation Board Lite: • ® ® ® ® For functional evaluation: PC with Microsoft...

  • Page 6: Evaluation Board Basic Setup

    The power supply input (VBAT) provides back-up power for those applications capable of using it. When a power supply is connected to VBAT, the ON/OFF switch, S2, turns the power supply to the 73S1210F on or off.

  • Page 7: Connecting The Evaluation Board With An Emulation Tool

    Loading Code with the In-Circuit Emulator If firmware exists in the 73S1210F flash memory, the memory must be erased before loading a new file into memory. In order to erase the flash memory, the RESET button in the emulator software must be...

  • Page 8: Figure 3: Emulator Window Showing Reset And Erase Buttons

    73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1210F_036 RESET BUTTON ERASE BUTTON Figure 3: Emulator Window Showing RESET and ERASE Buttons Figure 4: Emulator Window Showing Erased Flash Memory and File Load Menu Rev. 1.0...

  • Page 9: Using The Pccid Application

    UG_1210F_036 3 Using the PCCID Application The PCCID firmware is pre-installed on the 73S1210F Multi-SAM Evaluation Board Lite. It requires a PC with the serial RS-232 port. When powered-up, the board is able to run the PCCID demonstration host application which allows: •...
  • Page 10 73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1210F_036 Rev. 1.0...

  • Page 11: Evaluation Board Hardware Description

    4 Evaluation Board Hardware Description Jumpers, Switches and Modules Table 2 describes the 73S1210F Multi-SAM Evaluation Board Lite jumpers, switches and test points. The Item # in Table 2 references Figure 5. The default setting column refers to setup for running PCCID application.
  • Page 12 73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1210F_036 Schematic Item Default Name Silkscreen setting Reference SIM/SAM Card Allows the Multi-SAM Evaluation Board Lite to connector #3 communicate with a smart card using a SIM/SAM format: This slot is designated as #3 of the external 8010C multiplexed slots connected via the 73S1210F external card interface.
  • Page 13 73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1210F_036 Schematic Item Default Name Silkscreen setting Reference VPC test point Test point to monitor VPC. VPC is the input power source to the internal voltage converter. See the 73S1210F Data Sheet for further information.

  • Page 14: Figure 5: 73S1210F Multi-Sam Evaluation Board Lite Jumper, Switch And Test Point Locations

    73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1215F_036 Figure 5: 73S1210F Multi-SAM Evaluation Board Lite Jumper, Switch and Test Point Locations Rev. 1.8...

  • Page 15: Schematic

    100k 100k Apply 3.3V to pin 10 voltage to J3 or J4 27pF 27pF 27pF 27pF 27pF SIM/SAM Connector #1 SIM/SAM Connector #2 SIM/SAM Connector #3 SIM/SAM Connector #4 Figure 6: 73S1210F Multi-SAM Evaluation Board Lite Electrical Schematic Rev. 1.8...

  • Page 16: Pcb Layouts

    73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1215F_036 PCB Layouts Figure 7: 73S1210F Multi-SAM Evaluation Board Lite Top View (Silkscreen) Rev. 1.8...

  • Page 17: Figure 8: 73S1210F Multi-Sam Evaluation Board Lite Bottom View (Silkscreen)

    UG_1215F_036 73S1210F Multi-SAM Evaluation Board Lite User Guide Figure 8: 73S1210F Multi-SAM Evaluation Board Lite Bottom View (Silkscreen) Rev. 1.8...

  • Page 18: Figure 9: 73S1210F Multi-Sam Evaluation Board Lite Top Signal Layer

    73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1215F_036 Figure 9: 73S1210F Multi-SAM Evaluation Board Lite Top Signal Layer Rev. 1.8...

  • Page 19: Figure 10: 73S1210F Multi-Sam Evaluation Board Lite Middle Layer 1 - Ground Plane

    UG_1215F_036 73S1210F Multi-SAM Evaluation Board Lite User Guide Figure 10: 73S1210F Multi-SAM Evaluation Board Lite Middle Layer 1 – Ground Plane Rev. 1.8...

  • Page 20: Figure 11: 73S1210F Multi-Sam Evaluation Board Lite Middle Layer 2 - Supply Plane

    73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1215F_036 Figure 11: 73S1210F Multi-SAM Evaluation Board Lite Middle Layer 2 – Supply Plane Rev. 1.8...

  • Page 21: Figure 12: 73S1210F Multi-Sam Evaluation Board Lite Bottom Signal Layer

    UG_1215F_036 73S1210F Multi-SAM Evaluation Board Lite User Guide Figure 12: 73S1210F Multi-SAM Evaluation Board Lite Bottom Signal Layer Rev. 1.8...

  • Page 22: Bill Of Materials

    73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1215F_036 Bill of Materials Table 3 provides the bill of materials for the 73S1210F Multi-SAM Evaluation Board Lite schematic provided in Figure Table 3: 73S1210F Multi-SAM Evaluation Board Lite Bill of Materials Item...
  • Page 23 UG_1215F_036 73S1210F Multi-SAM Evaluation Board Lite User Guide Item Reference Part PCB Footprint Digikey Part Number Part Number Manufacturer R27,R29 P47KGCT-ND ERJ-3GEYJ473V Panasonic R30,R31 P3.0KGCT-ND ERJ-3GEYJ302V Panasonic S1,S2 P8051SCT EVQ-PJX05M Panasonic TP6,TP9-13 HEADER 2 x 1 S1011E-36-ND PBC36SAAN Sullins HEADER 2 x 6...

  • Page 24: Schematic Information

    The VPC input is the power supply input for the smart card power. It is recommended that both a 10 µF and a 0.1 µF capacitor are connected to provide proper decoupling for this input. Lastly, the PRES input on the 73S1210F contains a very weak Rev. 1.0...

  • Page 25: Multiplexer Configuration

    UG_1215F_036 73S1210F Multi-SAM Evaluation Board Lite User Guide pull down resistor. As a result, an additional external pull down resistor is recommended to prevent any system noise from triggering a false card event. The same holds true for the PRES input, except a pull up resistor is utilized as the logic is inverted from the PRES input.

  • Page 26: Figure 16: Multiplexer Circuit

    73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1215F_036 SCLK VPC2 C59 10uF 10uH XTALOUT 0.1uF XTALIN INTB PWRDN PRES 0.1uF VDDF_ADJ 73S8010C 4052 Slot_Sel_0 Slot_Sel_1 100k 100k 100k 100k 100k 100k 100k 100k 27pF 27pF 27pF 27pF 27pF SIM/SAM Connector #1...

  • Page 27: Multi-Sam Limitations

    VCC is ramping up, the RST will ramp up with VCC. This violates the ISO-7816 specification. However, the 73S1210F can select a specific card slot and initiate a valid reset so it will be activated normally and be placed into standby.

  • Page 28: Revision History

    73S1210F Multi-SAM Evaluation Board Lite User Guide UG_1215F_036 Revision History Revision Date Description August 20, 2009 First publication. Rev. 1.0...
